Laboratory nitrogen atmosphere muffle furnace with water chiller and mass flow controller
Pictures show of nitrogen atmosphere muffle furnace
Featrues of nitrogen atmosphere muffle furnace
1.Side door, easy to operate
2.High quality imported fiber, resistance high temperature
3.Programmable and PID automatic control
4.Heavy duty double layer structure with cooling fan. Lower temperature in outside case
5.Multi-function: Metal annealing, quenching atmosphere, surface cream, light treatment
6. Compact structure, can insert N2/Ar2 for special material sintering.
Technical parmaters of nitrogen atmosphere muffle furnace
| Model | CY-A1200 | CY-A1400 | CY-A1600 |
| Controller | LED/LCD for optional | ||
| Standard Furnace Hearth | 150*150*150mm | ||
| 150*150*200mm | |||
| 200*200*200mm | |||
| 200*200*300mm | |||
| 300*300*300mm | |||
| 300*300*400mm | |||
| 400*400*400mm | |||
| 500*500*500mm | |||
| 600*600*600mm | |||
| 800*800*800mm | |||
| Maximum Temperature | 1200℃ | 1400℃ | 1600℃ |
| Rated Temperature | 1100℃ | 1300℃ | 1500℃ |
| Heating Rate | 0-20℃ (suggestion 10℃/min) | 0-20℃ (suggestion 10℃/min) | 0-15℃ (suggestion 10℃/min) |
| Temperature Control | 30 programmable and PID automatic control ( customized) | ||
| Temperature uniform | ± 5℃ | ±5℃ | ±5℃ |
| Heating Element | Aludirome | SiC | MoSi2 |
| Thermocouple | K Type | S type | B type |
| Furnace Shell Structure | Double furnace shell and is equipped with cooling fan | ||
| Water cooling capacity | 50w/ ℃ | ||
| Tank capacity | 9L | ||
| Cooling water speed | 15L/min | ||
| Atmosphere acceptable | nitrogen, argon and other inert gases. Insert reduction gas is prohibited | ||
| Voltage | AC 110 -380V,50/60Hz, as customor require | ||
| Quality Guarantee | One year | ||
Large capacity nitrogen atmosphere muffle furnace
Packaging of nitrogen atmosphere muffle furnace
Standard PLY WOOD BOX as below picture show. or as customer request.
Shipping and transportation
As customer request. Generally, Our mode of transport are as by sea, by air or rail transport
Payment
T/T, L/C, WEST UNION, PAYPAL, ESCROW AND ETC
Warranty
Main product is 12 month, except wearing parts.
Relative accessories
Factory show
Zhengzhou CY Scientific Instrument Co., Ltd is mainly engaged in the research and development, design, manufacturing and sales of equipment used in scientific researches. Independence and innovation is the company's tenet. Welcome you come to visit us.
