argon gas sintering furnace price / sintering furnace price
Description of the protective atmosphere heat treatment furnace / atmosphere furnace
CYKY Atmosphere furnace can protect materials from oxidation and decarburization with flowing nitrogen and other inert gases. Atmosphere furnace is widely used in all kinds of colleges and universities laboratory, chemical laboratory, industrial and mining enterprises for chemical analysis, physical measures, as well as metal, ceramic sintering, such as piece of small steel heating, calcination, heat treatment.
Outstanding features of the atmosphere heat treatment furnace
1. Max. energy efficiency is achieved by surrounding the chamber with thermal-efficient alumina fiber ceramic insulation.
2. Heavy duty double layer structure with cooling fan. Lower temperature in outside case.
3. PID automatic control via current limiting phase angle fired the resistor,e.g SCR (Silicon Controlled Rectifier)
Technical parameters of the atmosphere furnace / protective atmosphere heat treatment furnace
Model | CY-A1700 | CY-A1400 | CY-A1200 | |||
Display | LED (also can be designed with touch screen temperature controller) | |||||
Max. temperature | 1700°C | 1400°C | 1200°C | |||
Working temperature | ≤1600°C | ≤1300°C | ≤1100°C | |||
Heating rate | Suggestion 0-20°C/min | Suggestion 0-20°C/min | Suggestion 0-30°C/min | |||
Temperature accuracy | +/-1°C | |||||
Standard chamber | 150×150×150mm ; 200*200*200mm; 200*200*300mm; 300*300*300mm ; 300*300*400mm (also we can design the chamber size as your requirement) | |||||
Heating element | MoSi2 rods | SiC rods | Resistance wire | |||
Thermal couple | B Type | S type | K type | |||
Temperature control | PID automatic control via SCR power control | |||||
Heating curves | 30 steps programmable | |||||
Working temperature | AC 110-480V 50-60Hz | |||||
Warranty | 12 month (exclusive wearing part) | |||||
Detailed photos of the atmosphere furnace / high temperature atmosphere heat treatment furnace
