With small size, light weight, easy operation, safety and easy maintenance, the TSM switchgear, as a new generation medium voltage electrical products, is playing a more and more important role in urban power system renewal and construction.
TSM switchgear dimensions
width: 375mm, 500mm, 750mm
length: 1800mm, `600mm
depth: 840mm
Specification:
Item |
Unit |
Parameters |
|
Rated voltage |
KV |
12 |
24 |
Rated frequency |
Hz |
50 |
|
Rated current |
A |
630/1250 |
|
Rated load breaking current |
A |
630 |
|
Rated short time withstand current (effective value) |
A |
20/31.5 |
|
Rated short circuit duration |
S |
3 |
|
Rated short circuit making current |
KA |
50 |
|
Rated peak withstand current |
KA |
50 |
|
Rated cable charging breaking current |
A |
10 |
|
Rated active load and close circuit breaking current |
A |
630 |
|
MAX transfer current |
A |
1750 |
|
Earthing switch short time withstand current (2s) |
KA |
17.4/20 |
|
For detailed specifications and dimensions, pls contact us.
We usually offer wooden packing for switchgears.
we can supply paid samples for test.
Usually we will offer a 12 months warranty.
If any problems resulted from quality and mal-manufacturing, our after-sales service will help you solve these problems.
We will help you with technical problems during installation and marketing.
Combining manufacturing experience, new technology and industrial knowledge, TENLEE aims to build advanced power distribution and protection systems.
TENLEE is specialized in manufacturing a comprehensive range of solutions from 12kv to 36kv for indoor/outdoor systems: complete medium voltage switchgear
vacuum circuit breakers
reclosers
load break switches
disconnector switches
cast-resin transformers from
power automation systems
We have several years of exporting experience. Our customers are all over the world, including Europe, Asia, Africa, America, Middle East. Most of our products export to Europe and are well recognized by them
1. What is the payment term?
T/T, wire transfer, west union
2. How about the warranty period?
Usually we offer a 12-month warranty period.
3.Do you have type test?
Yes, we have type test in China and we have also passed type test in Europe.
4.How can I order?
Please contact us and tell us your detailed request. Then we will send you our plan.
