Combining with advanced technology both at home and abroad, we developed TSM series indoorair insulated (modular SF6) switchgear (hereinafter referred to as switchgear) and TSC series (SIC and SQC type) indoor SF6 load break switch and composite apparatus.
It meets IEC298, IEC60420, IEC60265, GB 3906, GB3804, GB16926 standards. The switchgear has reliable fault operation prevention function.
We equipped gas-pressure meter on the load break switch to observe SF6 gas pressure when operating. Thus operation and servicing safety are ensured.
Other Schneider type switchgears are available.
1. Specification:
Item |
Unit |
Parameters |
||
Rated voltage |
KV |
12 |
24 |
|
Rated frequency |
Hz |
50 |
||
Rated current |
A |
630/1250 |
||
Rated load breaking current |
A |
630 |
||
Rated short time withstand current (effective value) |
A |
20/31.5 |
||
Rated short circuit duration |
S |
3 |
||
Rated short circuit making current |
KA |
50 |
||
Rated peak withstand current |
KA |
50 |
||
Rated cable charging breaking current |
A |
10 |
||
Rated active load and close circuit breaking current |
A |
630 |
||
MAX transfer current |
A |
1750 |
||
Earthing switch short time withstand current (2s) |
KA |
17.4/20 |
||
Rated current breaking times |
Times |
≥10 |
||
Load break switch mechanical life |
Times |
≥5000 |
||
Earthing switch mechanical life |
Times |
≥2000 |
||
1 min power frequency withstand voltage |
Common value |
KV |
42 |
55 |
Across insulate distance |
KV |
48 |
65 |
|
Lightning impulse withstand voltage |
Common value |
KV |
75 |
125/150 |
Across insulate distance |
KV |
85 |
150/160 |
|
Operating mechanism |
|
Manual or motor |
||
Operating voltage |
V |
AC/DC 220/110, DC48/24 |
||
Protection degree |
|
IP3X |
||
Wooden packages and cartons are optional.
FOB/EXW sea freight and air freight are available.
we can supply paid samples for test.
Usually we will offer a 12 months warranty.
If any problems resulted from quality and mal-manufacturing, our after-sales service will help you solve these problems.
We will help you with technical problems during installation and marketing.
Combining manufacturing experience, new technology and industrial knowledge, TENLEE aims to build advanced power distribution and protection systems.
TENLEE is specialized in manufacturing a comprehensive range of solutions from 12kv to 36kv for indoor/outdoor systems: complete medium voltage switchgear
vacuum circuit breakers
reclosers
load break switches
disconnector switches
cast-resin transformers from
power automation systems
We have several years of exporting experience. Our customers are all over the world, including Europe, Asia, Africa, America, Middle East. Most of our products export to Europe and are well recognized by them.
