Fixed Bitumen drum mix Plant
- 3 Set / Sets per Month
- Qingdao/Shanghai/Shandong
- T/T
- SHANTUI JANEOO STATIONARY ASPHALT BATCHING PLANT LB2000
- Asphalt Distributor Trucks and Trailers,Road Construction Paving Machinery Asphalt Distributor/Spreader Truck for Sale
- China Original Road Construction Machinery TM1000 Asphalt Mixing Plant Price on Sale
- China Original Road Construction Machinery TM1000 Asphalt Mixing Plant Price on Sale
- China Original Road Construction Machinery TM1000 Asphalt Mixing Plant Price on Sale
- China Original Road Construction Machinery TM1000 Asphalt Mixing Plant Price on Sale
Product Details
Condition: | New | Place of Origin: | Henan, China | Brand Name: | ZOOMLINE |
Model Number: | ZAP-C | Voltage: | 380V, 380V 60HZ or according requirements | Power(W): | 50HZ |
After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Specifications
High efficient 40T Drum Mix Asphalt PlantCapacity:40T/H
Drum mixing Type
High efficient Drum Mix Type Asphalt Plant
ZAP-C 40T Drum Mix Asphalt Mixing Plant
ZAP-C40 continuous asphalt mixing plant is mainly composed of cold supply system, inclined
belt feeder, dryer drum, burning system, elevator, dust collection system, finished products
storage bin, bitumen tank, mineral adding system and control system.
Features of ZAP-C40 asphalt mixing plant
1. Cold supply system of ZAP-C40-I asphalt mixing plant includes four hoppers and four
belt feeder, collection belt conveyor. This system adopts frequency speed control and
modular design while above the hopper equipped with grid, to prevent oversize aggregate
enter into small belt or drum.
2. Dryer drum of ZAP-C40 asphalt mixing plant adopts gear ring meshing transmission,
which is steady.
3. ZAP-C40 asphalt mixing plant Diesel Oil Burner system
4. The elevator plate chain of ZAP-C40 asphalt mixing plant adopts high strength wear-
resistant materials, Trailer reinforced with wear-resistant steel lip, make it has long
service life.
5. Dust collection system of ZAP-C40 asphalt mixing plant adopts six cylinder cyclone dust
6. Finished product storage bin of ZAP-C40 asphalt mixing plant has added material level sensor on the top part and has temperature sensor device at discharging port.
ZAP-C40 asphalt mixing plant | ||
Rated capacity | 40T/H | Standard condition |
Total power | 80kw | Standard configuration |
Cold aggregate kinds | 3 |
|
Rated drum drying capacity | 30T/H | 5% Moisture |
Fuel consumption | ≤6.5kg/t Finished product |
|
Fuel type | Heavy/ Light oil | Fuel coal is optional |
Control mode | Manual/ Automatic |
|
Finished product temperature | 140-180°C |
|
Aggregate weighting precision | ±1% | Continuous measurement |
Mineral weighting precision | ±0.5% | Continuous measurement |
Bitumen weighting precision | ±0.3% | Continuous measurement |
Direct-Heating Bitumen tank system
Drum mix type Asphalt control room
If you need the drum mix asphalt plant
pls contact: 0086-18838076770
Or send your inquiry to my email.
