80T Drum Mixing Asphalt Plant

Specifications

ZOOMLINE is the leading company in asphalt mixing plant and concrete mixing plant technology, support and service in China.
Henan ZOOMLINE Machinery CO.,Ltd is a professional supplier of turnkey asphalt mixing plant and concrete mixing plant solutions that draws on years' experience and technology development.

Our factory is located in the famous city of Nanyang, LiHe industrial park, Henan province. The factory covers an area of 160 mu (106000 square), and factory is divided into two area. The factory floor, workshop adopt advanced standardization management. Company has research and development department, engineering department, production department, sales and service department, etc.
Since ZOOMLINE start-up, we have become one of the most reliable partners of construction projects at home thorough ongoing technical investment. Our asphalt mixing plant and concrete mixing plant have been used in highways, high-grade highways, urban roads and airport construction and got high reputation for their excellent performance.
In recent years, we began to develop our overseas market. Nowadays, our asphalt plant products have been sold to Russia, Philippine, Kenya, Sri Lanka, Mongolia, Chile, Peru and Thailand etc.
Our asphalt plants and concrete plants have got CE, GOST and ISO9001 certification and we hold 18 patents which own to the concerted efforts of our employees.
Along with the high-quality products, genuine spare parts, we focus on providing better services. Now, we have a professional service group for our global customers. We dispatch our service personnel all over the world to help set-up asphalt or concrete plants and train operators.
ZOOMLINE will continue to strive for new technology and better solutions, while serving our customers with first-class products and excellent service.
For more information about ZOOMLINE and our products, please contact: Henan Zoomline Machinery CO.,LTD

80T Drum Mixing Asphalt Plant  80T Drum Mixing Asphalt Plant

ZAP-C80continuous asphalt mixing plant configuration and parameter

ZAP-C80  continuous asphalt mixing plant is mainly composed of cold supply system, inclined
belt feeder, dryer drum, burning system, elevator, dust collection system, finished products
storage bin, bitumen tank, mineral adding system and control system.

ZAP80 continuous asphalt mixing plant is mainly composed of cold supply system, RAP supply
system, drying system, dust collection system, finished products storage bin, bitumen tank,
mineral adding system and control system.

Features of ZAP80 asphalt mixing plant
1.Cold supply system of ZAP80 asphalt mixing plant includes four hoppers and four belt
feeder, Aggregate collection belt. This system adopts frequency speed control, with stable
performance.

2.Dry drum of ZAP80 asphalt mixing plant adopts wheel gear and gear ring meshing
transmission, transmit stable; With RAP add port in the middle of dry drum, can add
renewable materials. Drying system of ZAP80 asphalt mixing plant has mineral powder add
port, can add powder etc.

3. For burning system of ZAP80 asphalt mixing plant, the coal is optional.

4. Dust collection system of ZAP80 asphalt mixing plant includes gravity dust collector, bag
house dust collector etc.

5. Finished product storage bin of ZAP80 asphalt mixing plant has added material level
sensor on the top part and has temperature sensor device at discharging port.

6. Bitumen tank of ZAP80 asphalt mixing plant adopts high-precision flow meter, according to
the aggregate ratio, real-time tracking mix to ensure that the "oil-aggregate ratio" exact.

7.Electrical control system of ZAP80 asphalt mixing plant adopts table type operation panel,
main components are national famous brand CHINT or DELIXI, has interlock and secondary
protection function; Operation panel equipped with manual control device, main motor current
display, finished product temperature display and cold aggregate, coal, bitumen, mineral
powder frequency control; easy to operate.

Performance of ZAP80 asphalt mixing plant
1.Capacity of ZAP80 asphalt mixing plant under standard condition is 80t/h;
2. Fuel consumption of ZAP80 asphalt mixing plant under standard condition is 6.5kg/t;
3. Operation type of ZAP80 asphalt mixing plant includes both manual and auto;
4. Overall outer dimension of ZAP80 asphalt mixing plant is 33m×19m×12m;
5. Installation power of ZAP80 asphalt mixing plant is 183.62kW.

Whole series of batch asphalt concrete mixing plant, mobile asphalt concrete mixing plant, continuous asphalt concrete mixing plant and asphalt construction related ancillary
equipment
All HZS series of concrete mixing plant, HZS-B type cement concrete mixing plant, YHZS cement concrete mixing plant and other related ancillary equipment
Whole series of MFR pulverized coal burner, PMJ coal crusher and pulverized coal burner related ancillary equipment
Whole series of HPC pulverized coal burner, FMJ pulverized coal machine and related accessories
