ZAP-C 80T Continuous Asphalt Mixing Plant
- 3 Set / Sets per Month
- Qingdao/Shanghai/Shandong
- T/T
- SHANTUI JANEOO STATIONARY ASPHALT BATCHING PLANT LB2000
- Asphalt Distributor Trucks and Trailers,Road Construction Paving Machinery Asphalt Distributor/Spreader Truck for Sale
- China Original Road Construction Machinery TM1000 Asphalt Mixing Plant Price on Sale
- China Original Road Construction Machinery TM1000 Asphalt Mixing Plant Price on Sale
- China Original Road Construction Machinery TM1000 Asphalt Mixing Plant Price on Sale
- China Original Road Construction Machinery TM1000 Asphalt Mixing Plant Price on Sale
Product Details
Condition: | New | Place of Origin: | Henan, China | Brand Name: | ZOOMLINE |
Model Number: | ZAP-C | Voltage: | 380V, 380V 60HZ or according requirements | Power(W): | 50HZ |
After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
ZAP-C80continuous asphalt mixing plant configuration and parameter
ZAP-C80 continuous asphalt mixing plant is mainly composed of cold supply system, inclined
belt feeder, dryer drum, burning system, elevator, dust collection system, finished products
storage bin, bitumen tank, mineral adding system and control system.
CAP80 continuous asphalt mixing plant is mainly composed of cold supply system, RAP supply
system, drying system, dust collection system, finished products storage bin, bitumen tank,
mineral adding system and control system.
CAP80 asphalt mixing plant | ||
Rated capacity | 80T/H | Standard condition |
Total power | 183.62kw | Standard configuration |
Cold aggregate kinds | 4 |
|
Rated drum drying capacity | 80T/H | 5% Moisture |
Fuel consumption | ≤6.5kg/t Finished product |
|
Fuel type | Heavy/ Light oil | Fuel coal is optional |
Control mode | Manual/ Automatic |
|
Finished product temperature | 140-180°C |
|
Aggregate weighting precision | ±1% | Continuous measurement |
Mineral weighting precision | ±0.5% | Continuous measurement |
Bitumen weighting precision | ±0.3% | Continuous measurement |
Exhaust emission concentration | ≤50mg/Nm3 | Bag house dust collector |
Features of CAP80 asphalt mixing plant
1.Cold supply system of CAP80 asphalt mixing plant includes four hoppers and four belt
feeder, Aggregate collection belt. This system adopts frequency speed control, with stable
performance.
2.Dry drum of CAP80 asphalt mixing plant adopts wheel gear and gear ring meshing
transmission, transmit stable; With RAP add port in the middle of dry drum, can add
renewable materials. Drying system of CAP80 asphalt mixing plant has mineral powder add
port, can add powder etc.
3. For burning system of CAP80 asphalt mixing plant, the coal is optional.
4. Dust collection system of CAP80 asphalt mixing plant includes gravity dust collector, bag
house dust collector etc.
5. Finished product storage bin of CAP80 asphalt mixing plant has added material level
sensor on the top part and has temperature sensor device at discharging port.
6. Bitumen tank of CAP80 asphalt mixing plant adopts high-precision flow meter, according to
the aggregate ratio, real-time tracking mix to ensure that the "oil-aggregate ratio" exact.
7.Electrical control system of CAP80 asphalt mixing plant adopts table type operation panel,
main components are national famous brand CHINT or DELIXI, has interlock and secondary
protection function; Operation panel equipped with manual control device, main motor current
display, finished product temperature display and cold aggregate, coal, bitumen, mineral
powder frequency control; easy to operate.
Performance of CAP80 asphalt mixing plant
1.Capacity of CAP80 asphalt mixing plant under standard condition is 80t/h;
2. Fuel consumption of CAP80 asphalt mixing plant under standard condition is 6.5kg/t;
3. Operation type of CAP80 asphalt mixing plant includes both manual and auto;
4. Overall outer dimension of CAP80 asphalt mixing plant is 33m×19m×12m;
5. Installation power of CAP80 asphalt mixing plant is 183.62kW.
