SPG 500W-3000W Grid Hybrid Solar Power Inverter

SPG 500W-3000W Grid Hybrid Solar Power Inverter thumbnail-1
SPG 500W-3000W Grid Hybrid Solar Power Inverter photo-1
US$ 300 - 300 MOQ: 15 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
KEMAPOWER
Model Number:
Grid Hybrid Power Inverter Solar Power Guarder (SPG) 500W-3000W
Contact Supplier Request Quote Chat Now
Foshan Kemapower Electronics Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen/Guangzhou
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Brand Name KEMAPOWER
Model Number Grid Hybrid Power Inverter Solar Power Guarder (SPG) 500W-3000W
Specification Normal
Application Industrial
Output Voltage (V) 110 / 120V/ 220V/230V ±5% , 50HZ or 60HZ.
Load Power (W) 500W-3000W
Solar Power (W) 500W-3000W

 Key Features



 1. Solar energy first, grid power as
2.Combined AC charger and MPPT solar charge controller
3.MPPT solar controller to increase solar energy efficiency
4.Automatic transfer between grid power and solar power within 10ms
5. Plug and play design with the all breakers of solar power system
6.Wall mounted design with wired remote control
7.Power saver( stand by) function with lower idle consume
8. Battery selector for different battery to improve battery life
9.Rs232 communication is optional for LED mode
10.SNMP Net Agent card is optional for LED mode
11.LCD display is optional



Solar Power Inverter SPG SERIES TECHNOLOGY SPECS





Mode SPG500 SPG1000 SPG1500 SPG2000 SPG3000
Continuous power (W) 500W 1000W 1500W 2000W 3000W
Surge capability (W) 1500W 3000W 4500W 6000W 6000W
System DC input (VDC) 12V or 24VDC 24VDCV 24VDC 24VDC 24VDC
AC Output 110 / 120V/ 220V/230V ±5% , 50HZ or 60HZ. Terminal
AC Output waveform Pure Sine Wave
DC output 12VDC or 24VDC Terminal
Efficiency >85%
AC/DC Charger Max 15A Max 25A Max 25A Max 40AMP Max 50
Solar Charge Controller MPPT,20AMP MPPT,30AMP MPPT,40AMP MPPT,50AMP MPPT 100AMP
Adviced PV 36 or 72 Cell 72 Cell 72 Cell 72 Cell 72 Cell
External battery back 12 or 24VDC 24VDC 24VDC 24VDC 24VDC
Breakers with Breakers for AC Input , AC output, PV input , DC output
Battery low protection yes
Over discharge protection yes
Resume voltage yes. When fault remove
Over voltage protection yes
Overload protection yes.
With cooling fan yes
Display LED for Inverter,charger,Battery Capacity state, DC load state and fault. LCD display is optional
Running Temperature -35 degree to 55 degree
High temperature protection YES
Short circuit protection YES
Reverse polarity protection YES. Only for DC load side.
Stand by yes. continou ouput while > 25W
Communication RS232 Power Manager, NetAgent SNMP , Optional for LED mode
Package Size(mm) 608*558*293 608*558*293 608*558*293 608*558*293 608*558*293
Gross Weight KG 21 24 24 26 32
product Size (mm) 460*440*200 460*440*200 460*440*200 460*440*200 460*440*200
product weight( kg) 15KG 16KG 16KG 19.5KG 24KG



 SPG 500W-3000W Grid Hybrid Solar Power InverterSPG 500W-3000W Grid Hybrid Solar Power Inverter

SPG 500W-3000W Grid Hybrid Solar Power Inverter
