GIGA-LXC High Speed Cardboard Recycling Machine
US$ 600,000 - 1,100,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Application:
Other, Single facer for box macking line
Packaging Type:
Other, In bulk
Payment & Shipping
Payment Methods:
Port of Shipment:
PORT OF SHANGHAI
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
GIGI LX Computerized Corrugated Carton MachineUS$ 200,000 - 600,000MOQ: 1 Set -
GIGA LXC Auto Printing and Folding MachineUS$ 150,000 - 250,000MOQ: 1 Set
-
GIGA LXC High Quality Automatic Feeding For Gluing MachineUS$ 150,000 - 250,000MOQ: 1 Set
-
GIGA LX AFH1 Used Auto Feeder For Carton Making MachineUS$ 150,000 - 250,000MOQ: 1 Set
-
GIGA LX AFH1 Used Auto Feeder For Printer MachineUS$ 150,000 - 250,000MOQ: 1 Set
Condition
New
Application
Other, Single facer for box macking line
Packaging Type
Other, In bulk
Packaging Material
Plastic
Automatic Grade
Automatic
Driven Type
Electric
Voltage
380V
Power
70-85KW
Place of Origin
Shanghai, China
Brand Name
GIGA LX
Model Number
LX410S
Weight
11MT
Certification
CE
After-sales Service Provided
Engineers available to service machinery overseas
Specifications
1.Good quality for corrugated cardboard2.Rotation prevent glue dry
3.Oil compression methos
4.Cardboard recycling machine
LX-410S Single Facer for corrugated cardboard production line
- The maximum mechanical speed 250m/min
Max. width 2500mm
Main motor power 55KW with variable-frequency motor
Fan power 22KW
Hydraulic System Power 3.7KW - Compression method oil pressure
- Corrugated machine outside suction with no claw style guide;
The up and down movement for upper and lower corrugated rollers, pressure roller and glue roller are controlled by oil pressure. - When Host pause, the glue roller with rotation feature to prevent glue dry.
the gap between glue roller and absorption glue roller is precision measurement, touch screen display, electric adjustment, and automatic adjustment according to the machine speed. - Independent drive box with universal joint transmission.
- Cardboard machine roller adopts 48CrMo alloy steel, with heat treatment for hardness HRC58-62 degree, and the surface is well treated by grind; tungsten carbide corrugated roller for optional. gluing machine is also made in good quality.
- Electrically insulate glue device, adjusting the width of glue sizing convenient and fast.
- Corrugated cardboard machine and high speed cardboard recycling machine single facer with gluing machine are made in good quality.
We provide loan to below business situation
1. The value of order over RMB 1 million (including 1 million).
2. Only for boxing machine LX308N, LX-608CN LX707N or corrugated machine production line include LXC-180NN, LXC-220H1.8N models.
3. We accept O/A (Open account), it based on the credit level of buyer's bank credit report.
4. The details please consult with our sales department.
