GIGA LXC High Quality Automatic Feeding For Gluing Machine

Name: GIGA LXC High Quality Automatic Feeding For Gluing Machine
Brand: GIGA LX
SKU: 112008833
Availability: InStock

US$ 150,000 - 250,000 MOQ: 1 Set

Key Specifications

Condition:

New

Application:

Other, Carton box making machine

Packaging Type:

Other, In bulk

Shanghai Liu Xiang General Equipments Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

PORT OF SHANGHAI

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Application Other, Carton box making machine

Packaging Type Other, In bulk

Packaging Material Plastic

Automatic Grade Automatic

Driven Type Electric

Power 11-13KW

Place of Origin Shanghai, China

Brand Name GIGA LX

Model Number LX-AFH2

Specifications

Lifting power of horizontal
hydraulic drive
Synchronous in carton machine
High quality Auto Feeder
Gluing machine

LX-AFH2 Auto corrugated cardboard feeder for carton

High quality Auto Feeder

Gluing machine

Max paperboard size: 900 X 2400 mm
Paperboard stacking height : 1800 mm
Max. stacking weight: 2000 Kg
Paperboard lifting type, Fork lifted by chain
Power of fork rotating,Hydraulic driving
Lifting power of horizontal conveyor Hydraulic driving
The LX-AFH2 auto feeder can be moved lengthwise.
Carton feeder height between clap paper down and ground 1200mm
Corrugated cardboard feeder machine roller is ground fixed type
Fork push cardboard feeding automatically
The whole equipment can work with carton machinery Synchronously.
Transmission in side has side baffle ,electric-adjust telescopic.
Front of the conveyor belt has automatic lengthwise clap paper device(suit with printing machine clap enter and exit), down part has down limit.
Level conveyor belt can auto-control feeding (printing machine photoelectric control
), frequency control
Chain push cardboard up by rocker-type limit switch(or photoelectricity), carton feeder, carton making machine and carton machinery and auto sheet feeder for carton in good quality.
