PE series Jaw Crusher Information
PE series Jaw Crusher main parameters
| Model | Feed Opening(mm) | Max. Feed Size (mm) | Discharge Size (mm) | Capacity (t/h) | Rotation speed (r/min) | Motor power (KW) | Overall Dimension (mm) | Weight (T) |
| PE-400×600 | 400×600 | ≤340 | 40-90 | 15-40 | 270 | 30 | 1450×1750 ×1672 | 6.5 |
| PE-500×750 | 500×750 | ≤420 | 50-100 | 20-52 | 270 | 55 | 1600×1970 ×1950 | 9.3 |
| PE-500×750 | 500×750 | ≤480 | 50-110 | 20-80 | 270 | 55 | 1892×1964 ×2010 | 11.5 |
| PE-600×900 | 600×900 | ≤520 | 65-130 | 50-150 | 260 | 75 | 2075×2128 ×2390 | 16.6 |
| PE-700×1000 | 700×1000 | ≤600 | 70-140 | 80-170 | 260 | 90 | 2500×2286 ×2435 | 22 |
| PE-750×1060 | 750×1060 | ≤630 | 80-140 | 100-180 | 250 | 110 | 2770×2380 ×2972 | 29.3 |
| PE-800×1100 | 800×1100 | ≤700 | 100-200 | 120-230 | 250 | 110 | 2955×2390 ×2972 | 29 |
| PE-900×1100 | 900×1100 | ≤800 | 100-200 | 130-250 | 250 | 132 | 35 | |
| PE-900×1200 | 900×1200 | ≤800 | 100-230 | 180-280 | 250 | 132 | 3300×2820 ×3410 | 55 |
| PE-1000×1200 | 1000×1200 | ≤900 | 140-250 | 200-400 | 200 | 132 | 3435×3182 ×3025 | 60 |
| PE-1100×1300 | 1100×1300 | ≤1000 | 170-280 | 300-600 | 180 | 160 | 72 | |
| PE-1200×1500 | 1200×1500 | ≤1100 | 180-300 | 400-800 | 180 | 160 | 4200 |
PE series Jaw Crusher
Performance features of Jaw Crusher
1. The grain size of charge is big, the breaking ratio is big. the productivity is high.
2. The operation is stable and reliable,fixed with over-loading protective device.
3. The energe consumption is low, the throwaway parts are little,the maintenance cost is low.
4. The adjusting parts are reinforced emphatically. and precisi on working, reduce the frequency of rapair.
5. The bearing part adopts multilayer labyrinth craft, to prolong the operating life of the bearing.
6. Adopt the way of mould lubrication, the maintenance work is quicker and more convenient.
7. The pulley adopts new craft and to be locked tensely, connects without keys, the maintenance is more convenient.
Applicability of Jaw Crusher
1. Widely applied to all sorts of ore,rock etc whose breaking compressive strength is below 320Mpa.
2. Be widely used for the crafts of mine, metallurgy, road-bridge, building materials, water conservancy, chemical industry etc.
Jaw crusher in our factory
Construstion site
