Concrete perlite block machine QT40-2 information
1>Advantages of QT40-2 Concrete perlite block machine
1. QT40-2 Concrete perlite block machine can produce different bricks by changing mould.
2. QT40-2 Concrete perlite block machine has rational design, excellent performance, and is equipped with powerful vibration motor. The block is of good quality, large density and high strength.
3. The block is of good quality, large density and high strength. The machine used on the push mode, and automatic scraper, convenient and flexible operation, and its performance can be comparable with the large-scale equipment
4. We are a leading Manufacturer of semi-automatic block making machine, concrete block machine, brick making machine, cement brick machine, automatic block making machine, paver brick machine, hollow block machine, cement block making machine, aerated concrete for many years.
2> QT40-2 Concrete perlite block machine capacity Table
Size(L x W x H) |
Pcs /Mould |
Pcs / Hr |
Pcs/day |
400x200x200mm |
4 |
360 |
2880-3600 |
400x240x200mm |
5 |
450 |
3600-4500 |
3> QT40-2 Concrete perlite block machine specification
Main specification and technical parameters | |
Overall size |
1350(L)×1460(W)×1800(H)mm |
Shaping cycle |
40-45 seconds |
Pallet size |
850x450x25mm (bamboo) |
850x450x20mm (bamboo) | |
Vibration frequency |
2800 r.pm |
Upper vibrator |
2.2KW |
Nether vibrator |
4.4kw |
Electricity |
380V/220V/ (adjustable) |
Total weight |
1800 KGS |
4>JD350 mixer specification
Main specification and technical parameters | |
Overall size |
1200(L)×1200(W)×1300(H)mm(assembled) |
1200(L)×1200(W)×800(H)mm(seperated) | |
Shaping cycle |
5 mins |
Volume |
350L (25Kgs Cement) |
Electricity |
380V/220V/ (adjustable) |
Total weight |
330KGS |
5>QT40-2 small concrete brick machine photos
Welcome to our facctory
QT40-2 machine loading
Certification
Thanks for your attention, waiting to talk more details with you.
Contact: Betty Skype: bettyliu4260 Tel: 0086-18315730268
