Specifications
KB-125C pressure & vibration table concrete roof tile machine3000-4000pcs per day
roof tile, ridge
KB-125C pressure & vibration table concrete roof tile machine
KB-125C pressure & vibration table concrete roof tile machine
it uses Vibration table instead of Hydraulic pressure:
-- main tile, ridge tile, margin tile, end tile...etc
-- pallet is plastic, form tightly
-- capability 3000pcs per shift
1. vibration table use vibration theory to make tiles
2. full automatic, including mixer, feeder and tile machine
3. pallet is plastic
4. all roof tiles are available
1.Process production of molded KB-125C
Let the raw material cement and sand match according to a certain proportion.At the beginning the bucket elevator send the raw materials to the mixer,then the mixing materials can be put into the constant feeder,the constant feeder continuous uniform feed,the material be conveyed to the main machine color tile machine,that is,molded color tile machine.the tile can be produced by hydraulic cylinder and mold force.After drying by sun and maintain,then you can paint tiles.
2.The Consist of KB-125C
1.Molding Tile Forming Machine
2.Wheel Agitator
3.Automatic Weighing and Feeding Machine
4.Bucket Elevator
3.Process Flow of KB-125C
1.Preparing the raw material
Cement 1.5 Medium Sand 2.0 Coal Ash 0.5
2. Bucket Elevator
3.Wheel Agitator
4.Automatic Weighing and Feeding Machine
5.Curing Pallet
6.Hand Fork Lifter
7.Coating Line
8.Finished Goods
Roof tile Work flow: Elevating--- Mixing --- Fixed-quantity filling --- Pressure forming --- Mould unloading --- Forming tiles --- Onto the tiles shelf ---Maintenance (24 hours) --- Stacking --- Natural maintenance --- Ink jetting --- Finished products.
5.Feature of KB-125C
1.The machine adopts PLC programmable controller featuring fast molding speed,large output,automatic control,man-machine interface,reliable performance and convenient operation,It has 8 pieces/Min,whole hydro-pneumatic production speed,high rate of finished products and high cost performance.
2.As a competitive concrete products making equipment,its products adopts mortar concrete filter pressing molding and features perfect structure.Various style,high density,high intensity and accurate size,which can meet the needs of different constructions.
3.It is multifunctional machine,it can be used to produce various styles of main tiles,ridge tiles. Edge tiles and ditch tiles after changing the molds as well as different styles of high grade concrete ground tiles,such as terrazzo tiles,polishing and roto-blasting ground tiles and washing ground tiles.
4.Its remote diagnosis system,which can be used to control and diagnosis the equipment remotely through the phone line,greatly reduces the requirement for customers and makes the machine more humanization.
5.KB-125C terrazzo tile machine/automatic concrete roof tile making machine, having a high quality but low price,occupies the market share by its perfect products.
6.Stuffer pot adopts unique feeding head design, which ensures the complete matching of large quantity of filler incorporation and uniformity of threading, with high production of the complete machine.
6.Detailed Production of KB-125C concrete roof tile machine vibration table
1). bucket for raw material
2). wheel mixer
3). constant feeder
7.Technical Parameter of KB-125C
| KB-125C concrete tile machine/automatic concrete roof tile making machine | |
| moulding presure | 125T |
| moulding speed | 7-8pcs/min,more than 3000pcs/shift |
| main frame power | 5.5 KW |
| main frame weight | about 5T |
| external dimension | 2700*1600*2480mm |
Delivery of KB-125C concrete tile machine/automatic concrete roof tile making machine
if you have any question, pls feel free to contact with me of following information. If you have time, welcome you to visit our factory :
