GYTC8S Figure 8 Aerial Optic Fiber Communication Cable From Manufacturer
Introduction:
The fibers,either of singlemode or multimode type, are placed in a loose tube made of high modulus plastic. The tubes are filled with a waterresistant filling compound. A FRP locates in the center of core as a metallic strength member. The tubes (and fillers) are stranded around the strength member into a compact and circular cable core. After water blocking tape is applied around the cable core, this part of cable accompanied with the stranded wires as the supporting part are completed with a polyethylene (PE) sheath to be figure 8 structure. This kind of cable is specifically applied for self-supporting aerial installation.
Features:
1.Good mechanical and temperature performance.
2.High strength loose tube that is hydrolysis resistant.
3.Special tube filling compound ensure a critical protection of fiber.
Main Technical Parameters:
Cable Type |
Fiber Count |
Tubes |
Fillers |
Cable Diameter mm |
Cable Weight kg/km |
Tensile Strength Long/Short Term N |
Crush Resistance Long/Short Term N/100mm |
Bending Radius Static mm |
GYTC8S-2~6 |
2~6 |
1 |
4 |
9.5×18.3 |
218 |
600/1500 |
300/1000 |
10D/20D |
GYTC8S-8~12 |
8~12 |
2 |
3 |
9.5×18.3 |
218 |
600/1500 |
300/1000 |
10D/20D |
GYTC8S-14~18 |
14~18 |
3 |
2 |
9.5×18.3 |
218 |
600/1500 |
300/1000 |
10D/20D |
GYTC8S -20~24 |
20~24 |
4 |
1 |
9.5×18.3 |
218 |
600/1500 |
300/1000 |
10D/20D |
GYTC8S-26~30 |
26~30 |
5 |
0 |
9.5×18.3 |
218 |
600/1500 |
300/1000 |
10D/20D |
