6 Core GYFTY Optic Fiber Cable From Professional Manufacturer
Introduction:
The instruction of GYFTY53 is the single mode or multimode inserted to loosely tube by high the plastic of moudle. Filling warting blocking material in the tube. One single nonmetal strength member(FRP) in the mid of cable, added a layer of polyethylene sheath on FRP for some cores of fiber cable. armored steel tape for protecting. Finally, all of parts packed with PE sheath are extruded to cable by machine.
Main Technical Parameters:
Fiber Parameters:
No. |
Items |
unit |
Specification |
|
62.5/125 | ||||
1 |
Core Diameter |
μm |
62.5±2.5 |
|
2 |
Cladding Diameter |
μm |
124.8±1.0 |
|
3 |
Cladding Non-Circularity |
% |
≤1.0 |
|
4 |
Core-Cladding Concentricity Error |
μm |
≤1.5 |
|
5 |
Coating Diameter |
μm |
245±7 |
|
6 |
Coating Non-Circularity |
% |
≤6.0 |
|
7 |
Cladding-Coating Concentricity Error |
μm |
≤12.0 |
|
8 |
Bandwidth(min.) |
850nm |
MHz·km |
200 |
1300nm |
MHz·km |
600 |
||
9 |
Attenuation Coefficient |
850nm |
dB/km |
≤2.7 |
1300nm |
dB/km |
≤0.6 |
||
Cable Parameters:
Items |
Specifications |
|
Fiber Count |
6 |
|
Colored Coating Fiber |
Dimension |
250±15μm |
Color |
Blue,Orange,Blue,Brown,Grey, White |
|
Cable Subunit |
Dimension |
2.6±0.1mm |
Material |
PBT |
|
Color |
Natural, |
|
Filler |
Dimension |
2.6±0.1mm |
Material |
PP |
|
Color |
Natural,Natural,Natural,Natural,Natural |
|
Central Strength Member |
Dimension |
2.6mm |
Material |
FRP |
|
Outer Jacket |
Dimension |
12±0.2mm |
Material |
PE |
|
Color |
Black |
|
Mechanical and Environmental Characteristics:
Items |
Unite |
Specifications |
Tension(Long Term) |
N |
1000 |
Tension(Short Term) |
N |
2000 |
Crush(Long Term) |
N/10cm |
300 |
Crush(Short Term) |
N/10cm |
1000 |
Min. Bend Radius(Dynamic) |
mm |
20D |
Min. Bend Radius(Static) |
mm |
10D |
Installation Temperature |
℃ |
-10~+40 |
Operating Temperature |
℃ |
-40~+70 |
Storage Temperature |
℃ |
-40~+70 |
Pictures:
