8 Core Outdoor Armoured Stranded Loose Tube Waterproof Outdoor Fiber Optic Cable(GYTA/S)
GYTA/S fiber optic cable is used for duct or aerial applications.These aluminum tape armored cables are suitable for installation for long haul communication and LANs, especially suitable for the situation of high requirements of moisture resistance.
It is the stranded loose tube fiber optic cable with compact structure; the cable jacket is made of strong Polyethylene; High strength loose tube that is hydrolysis resistant; Cable filling materials ensure high reliability; APL or Steel Rape makes the cable crush resistant and moisture proof. So, the GYTA has a very good watertight performance.
Fiber Count:8 Fibers
Strength Member Materials:Steel Wire
Fiber Type:Singlemode G.652D
Armor Layer:Aluminum tape
Outer Sheath:PE (Default)
| G.652D | 50/125µm | 62.5/125µm | ||
|
Attenuation (+20°C) (dB/km) |
@850nm | ≤3.0 | ≤3.0 | |
| @1300nm | ≤1.0 | ≤1.0 | ||
| @1310nm | ≤0.36 | |||
| @1550nm | ≤0.22 | |||
| Bandwidth (Class A) (MHz·km) | @850nm | ≥600 | ≥200 | |
| @1300nm | ≥1200 | ≥600 | ||
| Numerical Aperture | 0.200±0.015NA | 0.275±0.015NA | ||
| Cable Cut-off Wavelength λcc (nm) | ≤1260 | |||
| Cable Count |
Out Sheath Diameter |
Weight |
Minimum Allowable Tensile Strength (N) |
Minimum Allowable Crush Load (N/100mm) |
Minimum Bending Radius (MM) |
Storage Temperature |
|||
| (MM) | (KG) | short term | long term | short term | long term | short term | long term | (℃) | |
| 2-24 | 9.5 | 110 | 1500 | 600 | 1000 | 300 | 20D | 10D | -40+60 |
| 26-42 | 10.5 | 135 | 1500 | 600 | 1000 | 300 | 20D | 10D | -40+60 |
| 46-72 | 11.5 | 155 | 1500 | 600 | 1000 | 300 | 20D | 10D | -40+60 |
| 74-96 | 13 | 175 | 1500 | 600 | 1000 | 300 | 20D | 10D | -40+60 |
| 98-120 | 14.5 | 200 | 2000 | 600 | 1000 | 300 | 20D | 10D | -40+60 |
| 122-144 | 15.5 | 270 | 2000 | 600 | 1000 | 300 | 20D | 10D | -40+60 |
