Ultraviolet Sterilizer Lamp Disinfection Device

Ultraviolet Sterilizer Lamp Disinfection Device thumbnail-1
Ultraviolet Sterilizer Lamp Disinfection Device thumbnail-2
Ultraviolet Sterilizer Lamp Disinfection Device thumbnail-3
Ultraviolet Sterilizer Lamp Disinfection Device photo-1
Ultraviolet Sterilizer Lamp Disinfection Device photo-2
Ultraviolet Sterilizer Lamp Disinfection Device photo-3
US$ 2,630 - 3,150 MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Shandong, China
Brand Name:
YiMei
Model Number:
YM-UUVC-240
Contact Supplier Request Quote Chat Now
Qingdao Yimei Environment Project Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
QINGDAO
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Shandong, China
Brand Name YiMei
Model Number YM-UUVC-240
Product Description



UV Sterilizer for Water Treatment

 I.  UV Sterilizer for Water Treatment Description



UV Disinfection is the most environmental protection, effective, safety and economical way to kill all bacteria, viruses, yeast, mold and algae, without adding any chemicals, so it takes no harm to human body and environment. The UV Disinfection ethnic is recommended to used in all drinking water and wastewater disinfection



 II.  UV Sterilizer for Water Treatment Component



Chamber: Stainless steel 304 or 316.



UVC lamp: Low pressure amalgam UV lamp. The lamp is the low pressure high intensity UV lamp.



Preheating improves the lamp lifetime. 254nm wavelength, more than 12000 hours service life. The lamp is operated and controlled by the electronic ballast of variable power output. The UV output is adjustable between 50%~100%.



Quartz Sleeve & Seal Ring: High transmittance more than 92%. Protection class: IP68; Thickness of tube wall: 1.5mm;



Electrical Cabinet: Housing material: 304 stainless steel; with voltmeter, timer (non-resettable), leakage



protection, fail alarm system; ballast (with CE certificate), Automatic UV Intensity Monitoring System,



Auto-cleaning System: drive by compressed air, set or adjusted by operator: once/1~500 hours, the cleaning ring is of UV resistant Teflon and Viton rubber.

 III.  UV Sterilizer for Water Treatment Application



2012 Advanced Water treatment UV Water Sterilizer is recommended in bellow industries: the electronics industry ultrapure water system sterilization; medicine, food, beverage, chemical, cosmetics and other industrial raw materials, water disinfection; purified drinking water, mineral water, mountain spring water disinfection; hospitals, hotels, restaurants, public places disinfection of the water supply system.



 IV.  UV Sterilizer for Water Treatment Hot Sale Model UV Sterilizer for Water Treatment





. Small flow rate type UV-Sterilizer



Model

Treatment capacity

 T/H

Inlet pipe Dia
mm

Power W

Working pressure
MPa

YM-UUVC-15

0.5

15

15

0.4

YM-UUVC-40

1.5-2

25

40

0.4

YM-UUVC-55

3-4

32

55

0.4

YM-UUVC-75

4-5

32

75

0.6

YM-UUVC-100

7-8

40

100

0.6

YM-UUVC-120

9-10

50

120

0.6

YM-UUVC-150

12-15

50

150

0.6

YM-UUVC-200

18-20

65

200

0.6

YM-UUVC-240

22-25

80

240

0.6





2. Big flow rate type uv-sterilizer



Model

Treatment capacity
T/H

Inlet pipe Dia
mm

power
W

Working pressure

 MPa

YM-UUVC-300

26-30

80

300

0.6

YM-UUVC-360

32-35

80

360

0.6

YM-UUVC-400

36-40

100

400

0.6

YM-UUVC-480

42-46

100

480

0.6

YM-UUVC-500

47-50

125

500

0.6

YM-UUVC-600

55-60

125

600

0.6

YM-UUVC-720

70-75

125

720

0.6

YM-UUVC-840

80-85

133

840

0.8

YM-UUVC-960

90-95

133

960

0.8

YM-UUVC-1080

100-110

150

1080

0.8

YM-UUVC-1200

120-130

150

1200

0.8

YM-UUVC-1320

140-150

200

1320

0.8

YM-UUVC-600

55-60

125

600

0.8

YM-UUVC-750

75-80

133

750

0.8

YM-UUVC-900

85-90

133

900

0.8

YM-UUVC-1050

110-120

150

1050

0.8

YM-UUVC-1200

120-130

150

1200

0.8

YM-UUVC-1350

150-160

200

1350

0.8

YM-UUVC-1440

160-170

200

1440

0.8

YM-UUVC-1500

180-200

200

1500

1.0

YM-UUVC-1650

220-250

250

1650

1.0

YM-UUVC-1800

280-300

250

1800

1.0

YM-UUVC-2400

350-400

250

2400

1.0

YM-UUVC-3000

460-500

250

3000

1.0

YM-UUVC-4200

600-650

300

4200

1.0

YM-UUVC-6000

800-900

350

6000

1.0
