Polyethylene Mixing Dosing Tank

PE mixing dosing tank

PE tank

  The PE mixing dosing tank is consisted of plastic tank and mixer for liquid, tank body, it is Rotomolding a molding tank which adopting imported PE raw material.

  Preinstall metering pump and mixer installation site, mixer,dosing tank,metering pump three in one, convenient to use. The product is tough, flexible, anti-impact and corrosion-resistant. The matching mixer is divided of direct stir and side stir, the direct mixer requires matched strengthening board and tanks, while the side mixer can be equip with fixed mount to improve its stir effect and tank body service life. The types of stirrer material is stainless steel.

Advantage:

The product is tough, flexible, anti-impact and corrosion-resistant. The matching mixer is divided of direct stir and side stir, the direct mixer requires matched strengthening board and tanks, while the side mixer can be equip with fixed mount to improve its stir effect and tank body service life. The types of stirrer material is stainless steel.

Apply scope:

  in water treatment mainly used in all kinds of agentia mixing,dissolve,storage, then pass by metering pump to dose solution .

Main components:

1.Metering pump
-Mechanical actuated diaphragm, no-leakage structure
-PVC,PTFE, PVDF,304,316 is available as the pump head material
-flow can be adjusted during operation, the range is   0.5~500L/h

Pressure range:0.2~1 Mpa
-Automatic  control who can accpet4~20mA is available (JWM-AD series)
-Motor: standard 220V/380V,50Hz

Regulating mode: manual / automatic

2.mixer

  Rated power :0.18~11kW;

 mixer diameter: 0.4~3m

mixing speed:60~200rpm

3.Solution tank

Material:PE,PVC

 Volume :1000L

Dosing Tank size:

 40L/80L/100L/120L/180L/200L/300L/500L/1000L/20

00L/3000L/4000L/5000L

Mixer power:

 0.18KW/0.37KW/0.55KW/0.75KW/1.1KW/1.5KW/2.2KW/3KW/4KW/5.5KW/7.5KW/11KW

                          Why choose us

1.Long history , companying with good reputation

2. Good quality control system , Huge financial resources invested, Management System Systematized, and service personalized, which will be our goal and persistent forever.

3. Huge market overseas . Our machines have been sold all over the world . especially Africa, Europe, Asia, and North America. Clients over many countries like Australia, Sri Lanka, UK, America, Mexico, Peru, Brazil, Kenya, Tanzania, Saudi Arab, UAE, etc.

4.Equipment working site , You are welcomed to visit our factory, the machines can be operated on site, and you will master the usage of machines nearby.

5. After-sales:

(1) 24 hours we are ready to explain question for you.

(2) Professional engineers supported, along with strong technical service.

(3) Excellent after-sales service.

(4) Any problem can be solved without influence products schedule of customers.
