Specifications

                                Plate and Frame Filter Press

Introduction:

The role of Plate frame type filter press is make the Scattered cloth slurry system of sludge special design form uniform wet board element in nets face, and multilayer wet combine, forming wet plate. The structure mainly consist of slurry uniform distribution machine,combine exposure paper system,forming dewatering system, blanket cleaning system structure etc, the slurry uniform distribution machine is developed by our company, specialized used in disperse slurry. The components of sludge is very complex, which contain fiber,many paddings and greater particles. as it need add Polymerization alumina and Polyacrylamide in water treatment process, make it has strong hydrophobicity, forming clustering conglobation, the general cloth slurry machine is difficult to make it dispersion, our cloth slurry machine solve this problem thoroughly, with high extensive adaptability.

The series press filter machine produced by our company is a kind of intermittent solid-liquid separation equipment, which is filter board, filter frame (plate frame type) or filter board (box) constitutes a filter chamber, under the action of the delivery pump, send the feed liquid into each filter chamber, via filter medium, make the solid and liquid separation. Which Widely used in chemical industry, dyestuff, oil ,ceramic, pharmaceutical, sugaring, food, starch , paint ,metallurgy and various industry of sewage treatment, etc.its specifications contain 200, 320, 450, 63, 800, 1000, 1250, 1,500 type, filtering area by 0.5 m2 ~ 500m2, filter board structure have plate frame type, van, diaphragm squeezing type; Heat- resisting temperature 0 ~ 120 °C, the filtrate outflow means has bright flow, undercurrent, washes, can not wash; Compaction methods: manual ,mechanical, hydraulic , automatic pressurize. Filter pressure from 0.2 ~ 1.6 Mpa, the plate and frame material is cast iron, Intensified Polypropylene,Glass fiber high temperature resistant polypropylene, stainless steel etc for choice.

Main Parameter:

 Chamber filter press:

Main material:

1.Mechanical electric integrated motorized hydraulic automatic pulling plate chamber filter press,hydraulic oil cylinder diameter 200MM ( it is made of 45 #seamless steel pipe,piston rod is 45 # steel); high-strength steel structure rack,panel is 16 Manganese plate, crossbeam is 16 manganess low carbon alloy steel plate (thickness 30mm), crossbeam bag stainless steel, stainless steel chain and pulling plate vessel.

2. Reinforced PP pure material filter plate, special acid-resisting thick filter cloth.

3. Electric adopt DELIXI, button switch adopt sanli, Mitsubishi PLC.

4. Hydraulic system hydraulic parts adopt Shanghai plunger pump2.5L,check valve,overflow valve, YTN ,solenoid valve etc.

main technique data
