Specifications

Chemcial Properties Stability
convenient maintenance
equipped with various safety device
hydraulic driven,PLC control

Chamber filter press:

Main material:

1.Mechanical electric integrated motorized hydraulic automatic pulling plate chamber filter press,hydraulic oil cylinder diameter 200MM ( it is made of 45 #seamless steel pipe,piston rod is 45 # steel); high-strength steel structure rack,panel is 16 Manganese plate, crossbeam is 16 manganess low carbon alloy steel plate (thickness 30mm), crossbeam bag stainless steel, stainless steel chain and pulling plate vessel.

2. Reinforced PP pure material filter plate, special acid-resisting thick filter cloth.

3. Electric adopt DELIXI, button switch adopt sanli, Mitsubishi PLC.

4. Hydraulic system hydraulic parts adopt Shanghai plunger pump2.5L,check valve,overflow valve, YTN ,solenoid valve etc.

main technique data

Specification	XMYZB20/630-UK	Remark
Filtering area (m2)	20	Electric hydraulic, automatic pressurize , Electric driven hydraulic
Filtering form	close flow double effluent water
Filter plate material	Pure fresh material polypropylene
Rack material	steel structure plate 16 manganese steel
Filter chamber volume	640
Filter plate specification (mm)	630x630
Filter plate thickness (mm)	50
Filter plate quantity (pcs)	31
Whole machine size (mm)	3420×840×1150mm
Motor power (kw)	1.5
Working pressure of filter chamber	0.6(Mpa)
Maximum Stroke Of maxi stroke	400MM
Filter cake thickness (mm)	28
Highest filtering temperature	<80°C
Oil cylinder working pressure	<18MPA
Whole weight(Kg)	1400KG



Why choose us

1.Long history , companying with good reputation



2. Good quality control system , Huge financial resources invested, Management System Systematized, and service personalized, which will be our goal and persistent forever.



3. Huge market overseas . Our machines have been sold all over the world . especially Africa, Europe, Asia, and North America. Clients over many countries like Australia, Sri Lanka, UK, America, Mexico, Peru, Brazil, Kenya, Tanzania, Saudi Arab, UAE, etc.



4.Equipment working site , You are welcomed to visit our factory, the machines can be operated on site, and you will master the usage of machines nearby.

5. After-sales:

(1) 24 hours we are ready to explain question for you.

(2) Professional engineers supported, along with strong technical service.

(3) Excellent after-sales service.

(4) Any problem can be solved without influence products schedule of customers.
