High Efficience Belt Filter Press for wastewater/ Solid-liquid seperation Belt Filter Press
A:How to select the right belt sludge dewatering machine?
A1:How about your sludge treatment capacity per hour(m3/hr)?
A2:How about your solid content or water content(%)?
A3:What is the character of your sludge?
A4:How about your dried sludge(D.S.)?
A5:How about your water content of sludge cake(%)?
Overview
Introduced the advanced technology from American, RBYL-Belt filter press is a sewage treatment device which can continuously press large amounts of sludge. By using high strength material, the device is characterized in large treating capacity, high dewatering efficiency and long service life. The high quality belt and long life bearing ensure the device’s performance and quality and make it widely used in the sewage treating industries.
Advantage
(1) Automatic control and continuous working
(2) Low energy cost and long service life
(3) High dewatering efficiency and high solid containing rate of mud cake
(4) Easy maintenance and management
(5) Low noise and less chemicals
(6) Economical and reliable, wide application.
Performance
Scientific design and reasonable layout ensure the high dehydration performance of the filter press. The main pressure roller adopts the hole design which increase the treating capacity and shorten the dehydration time by dewatering at the two sides of belt. The decrescent range of press role and the change contact angle of filter belt ensure the best combination of pressure and shear force so as to improve the solid containing rate and the efficiency of dehydration.
Characteristic
The tension of filter belt can be achieved through the air cylinder and keep in a constant. And the tension would not change with the inlet. It’s easy to operate and control. The press is equipped with the air compressor control system which can automatically correct and detect belt’s position on press role. For the belt press with a wider belt, there is an automatic sludge-in device which ensures the sludge can enter into the belt evenly, so as to improve the effect and lengthen the service life.
Structure
The device is equipped with two belts. There is a long gravity dehydration area which can improve the dehydration effect and lower the cost by reducing the usage of chemicals.
Technical data:
parameter |
Model |
||||||
YMYL-1000 |
YMYL-1500 |
YMYL-2000 |
YMYL-2500 |
YMYL-3000 |
YMYL-4000 |
||
Driven motor |
power (KW) |
1.0 |
1.5 |
2.2 |
4 |
5.5 |
7.5 |
Air compressor |
2.2 |
3 |
4 |
5.5 |
5.5 |
7.5 |
|
Belt width (mm) |
1000 |
1500 |
2000 |
2500 |
3000 |
4000 |
|
treatment capacity(m3/h) |
3~6.5 |
4-9.5 |
5-13 |
7-15 |
8-20 |
12-30 |
|
Outer size |
length(mm) |
5260 |
5260 |
5260 |
6200 |
7200 |
7800 |
width(mm) |
1400 |
1900 |
2400 |
2900 |
3623 |
4690 |
|
height(mm) |
2360 |
2360 |
2360 |
2500 |
2930 |
3030 |
|
Installation weight (kg) |
3 |
3.5 |
4 |
4.5 |
5 |
5.5 |
|
Inlet concentration (%) |
3~8% |
||||||
Outlet concentration (%) |
20~30% |
||||||
- Detailed installation manual and maintenance guideline are provided with the equipment.
- Technical training and site-commissioning are available for you.
- Any equipment issue, we will stand by.
Qingdao Yimei Environment Project Ltd. is found in 1988.We are located in the largest port city-Qingdao China. Our factary take up 36,000 square metres and there are more than 130 kinds machine for manufacturing. As a member of Shandong Province Environmental Protection Industrial Association, we have 360 staff and 72 experienced engineers.
Our main product is the equipment for Environment Protection and Waste Water Treatment.And the product is popular all over the world,such as Africa, North America,Domestic Market,Eastern Asia,Mid East.
♥Our company is professional for all kinds of sewage treatment plant, and our teams are all experienced for many years. we have our own factory.
if you are interesting in our products,you can feel free contact me.we would like to offer our best serivce to you.
