Help CenterIntermediate Aluminum Wire Drawing Machine
Related Products
-
Intermediate Copper Drawing MachineNegotiableMOQ: 1 Set -
Copper Wire Drawing Machine With AnnealerNegotiableMOQ: 1 Set
-
Intermediate Wire Drawing Machine With Continuous Annealer (gear)NegotiableMOQ: 1 Set
-
Intermediate Drawing Machine With Online AnnealerNegotiableMOQ: 1 Set
-
Intermediate Copper Wire Drawing Machine With Online AnnealerUS$ 50,000 - 80,000MOQ: 1 Set
Main technical data:
Drawing machine:
Inlet diameter: Max.Φ 3.5 mm
Outlet diameter: Φ0.8-Φ 2.0mm
Drawing speed: max 1800m/min
Drawing passes: max 17
Exterior diameter of dies : Φ25mm
Area reduction : the final die is 8%, others are 15%
Diameter of drawing capstan : Max. Φ300mm
Diameter of finished capstan : Φ 300mm
Power of drawing main motor : AC45 kw
installed power : 70 KVA
Control method : drawing and winding controlled by AC motors,
PID tension auto control, PLC+ human-machine interface
Bobbin : DIN 630
HT-630A spooler:
Max rotate Speed : 2000 r/min
Max. movable distance of the shaft: 150 mm
Max. travel distance of bobbin lifter: 150 mm
Spooling motor : AC 11kW
Traverse motor : 110W
Traverse width : 550mm
Bobbins : PND 500 and PND 630
Bobbin capacity : 300kgs~500 kgs
Brake : pneumatic-hydraulic pressure disc type;
Bobbin loading and unloading : by hydraulic liftor with motor;
Tension control : PID auto adjusting
Wire traverse speed : automatically detect the changes of the speed
Working pressure of the cylinder : 60 kg/cm2
