Specifications
Intermediate drawing machine with continuous annealer (Chain): Adopt precisely ground gears for all transmission system.Technical parameters
Inlet wire diameter: Φ3.0mm max
Outlet wire scope: Φ0.40-Φ1.60mm
Max dies No.: 17
Transmission type: by precision ground gears
Machine type: horizontal type with 4capstans
Max speed (MPM/Min): 2000
Slip ratio of M/C: 25%
Capstan slip ratio: 18.60%
Control system: PLC + man-machine interface
Motor control: Dual inverter control
Capstan: Tungsten
Capstan Dia.(Max): 250mm
Take-up dia.: Φ300-Φ630mm
Max power consumption: 70KW
Max loading capacity: 500kg
Lubrication type: Immersion
Annealing voltage(V): DC65
Annealing current(A): DC3500
Annealing power(KVA): 350
Lubrication type for bearing: Pump enforce oil
Dimension: 9500*3500*3400mm
