Help CenterHigh Speed Wire Drawing Machine
Related Products
-
Cu./AI./C-AI Alloy Wire Drawing Machine Fine Wire Drawing MachineNegotiableMOQ: 1 Set -
High Speed Wire Drawing MachineNegotiableMOQ: 1 Set
-
Fine Wire Drawing Machine With Annealer Slimline Machine Fine Line MachineNegotiableMOQ: 1 Set
-
15 Dies Wire Drawing MachineNegotiableMOQ: 1 Set
-
Fine Wire Drawing Machine and Double Spooler With Continuous AnnealerNegotiableMOQ: 1 Set
Technical specification
1) Machine Type: HT-24D
2) Intlet Diameter: 0.5mm~1.0mm
3) Outlet Diameter: 0.08mm~0.25mm
4) Drawing Line Speed: 2000m/min
5) Drawing Dies No./Max.: 24
6) Slip Ratio Of M/C: 13%
7) Fix Speed Capstan Slip Ratio: 8%
8) Capstan: Ceramic Plasma
9) Capstandia.(Max.) 194mm
10) Fix Speed Capstan Dia.: 159mm
11) Frame: Ironed Casted
12) Main Motor 11KW Three Phase Inductor Motor
13) Spooler Motor: 3.7KW Three Phase Inductor Motor
14) Spooler Control: Pid Synchronous Control Spooler
15) Inverter Control: Dual Inverter Control
16) Transmission Type: By Flat Belts
17) Send-Out Method: Over Head
18) Traversing Unit: Flat Belt+Synchronous Motor
19) Tension Control: Weight Balance By Swing Arm
20) Lubrication Type: Spray Type
21) Suitable Diameter Of Spool: 300
22) Capacity For Wire Receiving: 50-60
23) Bobbin Loading & Unloading Type: Shaft Brake
24) Power Source: 380V
25) Brake: Magnetic Brake
26) Machine Dimension : 2050L X 1600W X 1900H (mm)
27) Machine Weight: Approx. 2500KG
