Fine Wire Drawing Machine With Annealer Slimline Machine Fine Line Machine
Negotiable
MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Jiangsu, China
Brand Name:
HONTA
Model Number:
HT-22DTS
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
15 Dies Wire Drawing MachineNegotiableMOQ: 1 Set -
Fine Wire Drawing Machine and Double Spooler With Continuous AnnealerNegotiableMOQ: 1 Set
-
Fine Wire Drawing Machine With Double SpoolerNegotiableMOQ: 1 Set
-
Fine Wire Drawing Machine Double SpoolerNegotiableMOQ: 1 Set
-
15Dies Fine Wire Drawing Machine With Online Annealer Copper Wire Processing EquipmentUS$ 20,000 - 30,000MOQ: 1 Set
Place of Origin
Jiangsu, China
Brand Name
HONTA
Model Number
HT-22DTS
Usage
Drawing
Specifications
Drawing capstans arranged squarely can save space. Transmitted by high quality flat belts maintenance easy, low noise.Part one Features:
- Drawing capstans arranged squarely can save space.
- Transmitted by high quality flat belts maintenance easy, low noise.
- Two motors type can precisely control the spool wire tension to reduce the slip ratio of wire to a minimum manner
- Man-machine interface communication control, the digital operation, double transducers.
- Continuous annealing machine control system: DC control.
- Multi-zone annealing, annealing uniform.
- The automatic degree is high. It changes spoolers automatically when it spools the wire to the given length to achieve the purpose of continuous production. It saves time and labor.
Part two Technical data:
- Inlet dia. 0.6 - Φ1.2
- Outlet dia. 0.1- Φ0.43
- l Max dies No. 22
- Transmission type Flat belt
- Machine type 2 Capstans square type
- Max . speed(MPM/MIN) 1800
- Slip ratio of M/C 15.00%
- Capstan slip ratio 8.00%
- Control system PLC+ man-machine interface .
- Motor control Dual inverter control
- Capstan Ceramic
- Capstan Dia.(Max) 160
- Capstan Dia. 160
- Take-up Dia. Φ300/max
- Bobbin loading & unloading Shaft type
- Traversing unit Synchronize Motor type
- Main motor 15KW
- Take-up motor 4KW×2
- Top power consumption 23KW
- Synchronous control PID synchronous control spooler
- Tension control Weight balance by swing arm
- Max. loading weight 50KG
- Brake 10kg magnetic brake
- Lubrication type Spray type
- Annealing voltage DC65V
- Annealing current DC300A
- Annealing capacity 25KVA
- Lubrication type for bearing Without oil
- Power 3×380V 50Hz
- Machine size 3200×1600 1800
