CMC VT SERIES MINI VIBRATING SCREEN MACHINE PRICE

FOB Price

Negotiable / Set

1 Set(Min. Order)

Port Keelung/ Taiwan
Payment TermsT/T

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Type	Circular
Application	Ore	Place of Origin	Taiwan, China
Brand Name	CMC	Model Number	Refer to below list
Power(W)	15-60 HP	Certification	CMC
Warranty	one year	After-sales Service Provided	Engineers available to service machinery overseas

Product Description

vertical inclined screen

VT Series Inclined Screen

Taiwan Patents: 128342

China Patents: 313432

Japan Patents:3046504

Features:

♦ A fully new vibrating screen offers better screen efficiency, more convenient maintenance and robust structure

♦ High strength alloy frame plates, integrated fabricated screen decks and huck bolted structure compose ever robust frame

♦ Replaceable bearing seat design to easily change bearing and all parts at site

♦ Equipped with rubber spring (option) to have smooth start and stop operation

♦ Low running temperature in vibrator, especially suitable for dry screening

♦ Advanced vibrating Mechanism design with features of low power consumption, less lubricant and low noise meets requirement of modern environment protection

Advantages:

♦ Long bearing life due to advance vibrator without bending and heat stretch

♦ Long frame life time due to Intergral screen deck; high strength side plates and hucking bolt frame design

♦ Replaceable bearing seat design to easily change bearing and all parts at site

♦ Amplitude can be adjustable through counterweight

♦ Universal joint power transfer to minimize bearing loading

Specifications:

Model	Screen Area (m2)	Width (mm)	Length (mm)	Power (hp)	Speed (rpm)	Weight(kg)
Model	Screen Area (m2)	Width (mm)	Length (mm)	Power (hp)	Speed (rpm)	2 Decks	3 Decks
VT412	4.3	1200	3600	15HP*6P	780-880	2500	3500
VT516	7.2	1500	4800	25HP*6P	780-880	4200	5500
VT618	9.7	1800	5400	30HP*6P	780-880	4600	6200
VT722	13.8	2100	6600	40HP*6P	780-880	7300	8400
VT822	15.8	2400	6600	50HP*6P	780-880	8400	9900
VT824	17.2	2400	7200	60HP*6P	780-880	8700	10300

Last Update Time:2013-11-20
