Help CenterCMOS Camera Module OmniVision JAL-OV4689 V1.0 for Security Low Light Applications
Related Products
-
OV23850 OV21840 OV16825-2A OV16850 OV16860 OV16880 OV13850 OV13830 OV13853 OV13860 OV12830 HDR Camera ModulesNegotiableMOQ: 1 Piece -
HDR OV10625 OV10626 OV10633 OV10635 OV10640 OV10642 OV10823 OV9215-F48Y OV9712 OV9714 OV9715 OV9715-F48Y OV9718 Camera ModuleNegotiableMOQ: 1 Piece
-
OV5640 OV5645 OV5647 OV5648 OV5650 OV5653 OV5656 OV5658 OV5670 OV5680 OV5682 OV5630 Camera ModuleNegotiableMOQ: 1
-
0V4689 OV4688 OV4682 OV4683 RGB IR OV2724 OV2722 OV2715-1E OV2710-1E OV2685 OV2680 Camera ModuleNegotiableMOQ: 1 Piece
-
OV8825 OV5640 OV5648 OV5647 OV5650 OV5653 OV5642 OV3640 OV2655 OV2643 OV2642 OV2640 Camera ModuleNegotiableMOQ: 1 Piece
JAL-OV4689 V1.0 provides excellent image on day and night applications.
We offer with IR and without IR products on JAL-OV4689 V1.0
We also offer other image sensors such as OV5640, OV4682, OV13850, OV8865, IMX214, IMX135, IMX219, etc.
OmniVision OV4689 MIPI Interface Fixed Focus 4MP Camera Module
| Camera Module No. | JAL-OV4689 V1.0 |
| Image Sensor | OV4689 |
| EFL | 2.35 mm |
| F.NO | 2.5 |
| Pixel | 2688 x 1520 |
| View Angle | 160° |
| Lens Type | 1/3 inch |
| Lens Dimensions | 17 x 14.2 mm |
| Module Size | 40.05 x 17 mm |
| Module Type | Fixed Focus |
| Interface | MIPI |
| Mating Connector | AXK7L40223G |
High Frame Rate 4-Megapixel CameraChip™ Sensor with Excellent Low-Light Sensitivity and High Dynamic Range for Security Applications
The OV4689 is a high performance 4-megapixel CameraChip sensor in a native 16:9 format designed for next-generation surveillance and security systems. The sensor utilizes an advanced 2-micron OmniBSI-2™ pixel to provide best-in-class low-light sensitivity and high dynamic range (HDR).
The 1/3-inch OV4689 can capture full-resolution 4-megapixel high definition (HD) video at 90 frames per second (fps), 1080p HD at 120 fps, and binned 720p HD at 180 fps. The sensor's high frame rates enable crisp, clean image and video capture of fast moving objects.
The OV4689 provides timing to capture full-resolution HDR using frame-based "sequential HDR" or line-based "staggered HDR", and quarter resolution HDR using "alternate row HDR". The benefits of using "staggered HDR" compared to "sequential HDR" are significant reduction in motion artifacts and lower memory requirement for host processing. These modes produce
high quality full-resolution 4-megapixel HDR video under extreme variations of bright and dark conditions, ensuring high contrast and excellent scene reproduction.
The OV4689 features a high-speed 4-lane MIPI serial output interface to facilitate the required high data transfer rate. The OV4689 is available in a chip scale package (CSP).
We, as a team, always hope to establish a win-win business situation for our partners, we can share high return, quality products and excellent services. At the same time, we advocate the social responsibility of enterprise and maintain mutual respect and trust among all shareholders.
KLT -- KAI LAP TECHNOLOGIES GROUP LTD. is engaged in the manufacturing of CMOS Camera Module with a variety of specifications. KLT has attained advanced CMOS camera technologies, perfect quality assurance system, and close relationship with suppliers and customers in Hong Kong and the Mainland China.
Camera OEM Design Frequently Asked Questions
1. Does KLT provide OEM design service on camera modules?
Yes, we provide OEM design service. We can help you to design and produce the camera modules according to your requirements.
2. How can I get a customized camera module?
1) Provide your requirements to us, and our sales and engineering will work together towards the design the camera module.
2) We will create a technical drawing for your approval.
3) Upon approval on the technical drawing, we will make a new mold for the camera after receipt of NRE charge.
3. What is included in the NRE charge?
The NRE charge includes tooling up a new camera module, producing
5 pieces camera module samples for evaluation and shipping to your office.
4. How long will it take to get the customized sample?
1) The creation of the technical drawing takes about 5 to 7 days
2) The molding process takes about 20 to 25 days
3) The shipping time takes about 3 to 4 days
You may expect to receive your first 5 samples in about 30 to 35 days.
5. Does KLT have minimum order quantity requirement?
No. We do not have MOQ requirement for the customized camera module. However, the high purchase volume will lead to lower unit price.
