JAL-IRSW-OV4689 V1.0
OmniVision OV4689 with IR Switch MIPI Interface Fixed Focus 4MP Camera Module
| Camera Module No. | JAL-IRSW-OV4689 V1.0 |
| Image Sensor | OV4689 |
| EFL | 2.8 mm |
| F.NO | 2.0 |
| Pixel | 2688 x 1520 |
| View Angle | 130° |
| Lens Type | 1/3 inch |
| Lens Dimensions | 24 x 23.09 mm |
| Module Size | 34.5 x 56.07 mm |
| Module Type | Fixed Focus |
| Interface | MIPI |
| Mating Connector | FH12-24S-0.5SH |
| Pin No. | Pin Layout Description |
| 1 | AGND |
| 2 | AVDD2.8V |
| 3 | SDA/SIOD |
| 4 | SCL/SIOC |
| 5 | PWDNB |
| 6 | RST/XSHUNDN |
| 7 | MCP |
| 8 | MCN |
| 9 | DGND |
| 10 | MDP0 |
| 11 | MDN0 |
| 12 | DGND |
| 13 | MDP1 |
| 14 | MDN1 |
| 15 | DGND |
| 16 | MDP2 |
| 17 | MDN2 |
| 18 | DGND |
| 19 | MDP3 |
| 20 | MDN3 |
| 21 | DGND |
| 22 | DVDD1.2V |
| 23 | DOVDD1.8V |
| 24 | MCLK |
High Frame Rate 4-Megapixel CameraChip™ Sensor
with Excellent Low-Light Sensitivity and
High Dynamic Range for Security Applications
The OV4689 is a high performance 4-megapixel
CameraChip sensor in a native 16:9 format designed for
next-generation surveillance and security systems. The
sensor utilizes an advanced 2-micron OmniBSI-2™ pixel to
provide best-in-class low-light sensitivity and high
dynamic range (HDR).
The 1/3-inch OV4689 can capture full-resolution
4-megapixel high definition (HD) video at 90 frames per
second (fps), 1080p HD at 120 fps, and binned 720p HD
at 180 fps. The sensor's high frame rates enable crisp,
clean image and video capture of fast moving objects.
The OV4689 provides timing to capture full-resolution
HDR using frame-based "sequential HDR" or line-based
"staggered HDR", and quarter resolution HDR using
"alternate row HDR". The benefits of using "staggered
HDR" compared to "sequential HDR" are significant
reduction in motion artifacts and lower memory
requirement for host processing. These modes produce
high quality full-resolution 4-megapixel HDR video under
extreme variations of bright and dark conditions,
ensuring high contrast and excellent scene reproduction.
The OV4689 features a high-speed 4-lane MIPI serial
output interface to facilitate the required high data
transfer rate. The OV4689 is available in a chip scale
package (CSP).
