JAL-IRSW-OV4682 V1.0
OmniVision OV4682 with IR Switch MIPI Interface Fixed Focus 4MP Camera Module
| Camera Module No. | JAL-IRSW-OV4682 V1.0 |
| Image Sensor | OV4682 |
| EFL | 2.8 mm |
| F.NO | 2.0 |
| Pixel | 2688 x 1520 |
| View Angle | 130° |
| Lens Type | 1/3 inch |
| Lens Dimensions | 24 x 23.09 mm |
| Module Size | 34.5 x 56.07 mm |
| Module Type | Fixed Focus |
| Interface | MIPI |
| Add On | IR Switch |
| Mating Connector | FH12-24S-0.5SH |
| Pin No. | Pin Layout Description |
| 1 | AGND |
| 2 | AVDD2.8V |
| 3 | SDA/SIOD |
| 4 | SCL/SIOC |
| 5 | PWDNB |
| 6 | RST/XSHUNDN |
| 7 | MCP |
| 8 | MCN |
| 9 | DGND |
| 10 | MDP0 |
| 11 | MDN0 |
| 12 | DGND |
| 13 | MDP1 |
| 14 | MDN1 |
| 15 | DGND |
| 16 | MDP2 |
| 17 | MDN2 |
| 18 | DGND |
| 19 | MDP3 |
| 20 | MDN3 |
| 21 | DGND |
| 22 | DVDD1.2V |
| 23 | DOVDD1.8V |
| 24 | MCLK |
High Frame Rate 4-Megapixel CameraChip™ Sensor
with Excellent Low-Light Sensitivity and
High Dynamic Range for Security Applications
OmniVision's OV4682 is a 4-megapixel RGB infrared (IR)
single sensor that captures high-resolution images and
video as well as IR information. Its dual RGB and IR
capabilities allow it to bring a host of additional features
to mobile and machine vision applications, including
gesture sensing, depth analysis, iris detection and eye
tracking. By combining two capabilities into a single
sensor, the OV4682 reduces the total cost for the system
while also reducing the space required for multiple
sensors.
The sensor's 2-micron OmniBSI-2™ pixel delivers
excellent signal-to-noise ratio and IR sensitivity, and
offers best-in-class low-light sensitivity with a 40 percent
increase in sensitivity compared to the 1.75-micron
OmniBSI-2 pixel. The OV4682's unique architecture and
pixel optimization bring not only the best IR performance
but also best-in-class image quality. Additionally, the
sensor reduces system-level power consumption by
optimizing RGB and IR timing.
The OV4682 records full-resolution 4-megapixel video in
a native 16:9 format at 90 frames per second (fps), with a
quarter of the pixels dedicated to capturing IR. The
1/3-inch sensor can also record 1080p high definition
(HD) video at 120 fps with electronic image stabilization
(EIS), or 720p HD at 180 fps.
The OV4682 features a high-speed 4-lane MIPI serial
output interface to facilitate the required high data
transfer rate. It fits into an 8.5 x 8.5 mm module with a
z-height of less than 6 mm.
