Specifications
high qualityTorsion Testing Machine
torque tester
NJ-100S This series of testing machines for metal materials, non-metallic materials, composite materials and components to reverse the performance tests. According to national standards "GB/T10128-1998 metal at room temperature torsion test method" to test and provide data. Mainly applied to measure quality control; metallurgical steel; machinery manufacturing; civil aviation; institutions of higher learning; research laboratories; inspection arbitration, technical supervision departments; building materials ceramic; petrochemical industry; other industries Mechanics Laboratory.Features: This machine by the manual loading, high-precision torque sensor detects torque, encoders measure the rotation angle, liquid crystal display test results. The torsion testing machine has a simple structure, easy operation, low price and so on. Used to determine the material torque, maximum torque, angle and so the reverse indicator. Fine control of its powerful control, data processing capability, high reliability, the test machine using other processors can not match
Prime Technical Parameters: Max Test Torque = 100Nm Torque display value = 1-100Nm Relative Error of Torque Display-value = 1% Repetitive Error of Torque Display-value = 1% Measure Range of Torsional Angle = 0-9999.9 Relative Error of Torsional Angle Display-Value = 1% Max Distance between the Two Collet = 260mm Host Machine = 950x330x400mm Power Supply = 220V, 50Hz Weight = 100Kg
