Home > Instruments & Meters > Test Instrument > Test Machine > Torsion Testing Machine

Torsion Testing Machine

Name: Torsion Testing Machine
Brand: jingyuan
SKU: 111608055
Availability: InStock

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Get Latest Price

Place of Origin:

Zhejiang, China

Brand Name:

jingyuan

Model Number:

TTM

Contact Supplier Request Quote Chat Now

Jinhua East Instrument International Trade Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Ningbo

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Zhejiang, China

Brand Name jingyuan

Model Number TTM

Power Other

Usage Torsion Tester

Specifications

Torsion test of metal
non-metal and
composites specimens

Torsion Testing Machine

Product Description

TTM Torsion Testing Machine Capacity: 200Nm to 5000Nm Application: Torsion test of metal, non-metal and composites specimens Feature and uses: For maximum torsion testing versatility and capability, SUNS offers a full range of torsion testing machines in capacities from 200 to 5000 Nm. These uniquely superior torsion testers provide loading and weighing capabilities, this feature makes it possible to conveniently determine not only the ultimate torque load of a specimen, but how that specimen behaves under conditions of continuous or intermittent torque loading in both directions. Essentially, each torsion tester comprises a variable speed drive loading system and a digital control and indicating system in a fixed unit. The weighing head with its strain gage torque sensor is mounted on a moveable unit, which can position on the rails to accommodate specimens of varying lengths. 1. Micro computer control offers easy operation 2. Using servo motor driving ensures high performance of the whole system. 3. Employs a gear reduction system coupled directly to a variable speed drive motor. This reversible loading system provides positive, infinitely variable testing speeds 4. Electrical control system, high stability, smooth operation, fast response, low noise, adjust parameters according to different models 5. Have complete overload protection, emergency stop and other safety protection functions 6. Has a strong data and graphics processing capabilities, be available for printing out a test report and test curve 7. These uniquely superior torsion testers provide loading, twist angle measuring, load speed displaying, and weighing capabilities, etc. 8. Test data acquisition and display automatically, and can be print out with the date, No., material, torque, strength on it, which comply with the national standard test report 9. Specimen protection function prevents initial gripping force on specimens. 10. Conform to GB/T 10128-2007 Technical Specification: Model TTM202-A1 TTM502-A1 TTM103-A1 TTM203-A1 TTM303-A1 TTM503-A1 Max. torque(N·m) 200 500 1000 2000 3000 5000 Torque measurement

Model	TTM202-A1	TTM502-A1	TTM103-A1	TTM203-A1	TTM303-A1	TTM503-A1
Max. torque(N·m)	200	500	1000	2000	3000	5000
Torque measurement range (Nm)	1~100%
Accuracy	Class 1/0.5
Torque measurement accuracy	±1%(class 1 )/ ±0.5%(Class 0.5)
Torque resolution (Nm)	1/300000 of Max. torque
Twist anglerange (°)	0o-10000o
Twist angle accuracy	±1.0%
Torsion twist angle resolution	0.0045 o
Torsion twist angle accurancy	±1.0%
Torsion speed	6-720 o /min			6-500 o /min
Torsion speed accuracy	Within ±1.0% of set value
Span of two ends grips	650mm
Specimens diameter	Φ 6-Φ 20mm			Φ8-Φ28mm
Motor Power	0.2kW	0.4kW	0.75kW	1kW	2kW	4kW
Power supply	380±10% V/50Hz
Weight	300Kg		650Kg		1500Kg
