VMC420L Mini Cnc Vertical Machine Center

Name: VMC420L Mini Cnc Vertical Machine Center
Brand: GOOD
SKU: 111607353

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Condition:

New

Type:

Other, Vertical, Small low cost micro

Place of Origin:

Shandong, China

Tengzhou City Good CNC Machine Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Qingdao

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Type Other, Vertical, Small low cost micro

Place of Origin Shandong, China

Brand Name GOOD

Model Number VMC420L

VMC420L mini cnc vertical machine center

NO.	Item						Specification
1	Table size L(mm)×W(mm)						800×260
2	T slot QTY /width/interval distance(mm)						5-16-50
3	Maximum load(KG)						150
4	X travel (mm)						420
5	Y travel (mm)						270
6	Z travel (mm)						410
7	Spindle nose to table (mm)						70-480
8	Spindle center to column (mm)						315
9	Spindle taper						BT30
10	Max. spindle speed (Rpm)						6000 or 8000
11	Main motor (kW)						2.2
12	Feed motor	X torque (N.M)					4
		Y torque (N.M)					5
		Z torque (N.M)					6
		Max. install size			XY		Square 110×11diameter φ95
					Z		Square 130×130diameterφ110
13	Rapid moving speed (m/min.)						10
14	Cutting speed (mm/min)						1-4000
15	Ball screw (diameter/pitch )mm					XY	20/5
						Z	25/5
16	Linear guide way width (mm)					XY	20
						Z	25
17	Accuracy		Positioning accuracy (mm)				0.016
			Repeatability accuracy (mm)				0.008
18	Tool changer		Funnel type (optional ) BT30				10 or 8
			Tool changing time (s)			Funnel type	8
19	Air pressure (Mpa)						0.6
20	Machine weight (kg)			Frame			800
				Complete machine			1300
21	Machine overall size : L(mm)×W(mm)×H(mm)			Frame			830×1000×1800
				Complete machine			1900×1400×2100
