Label/ Sticker Die Cutting Machine

Label/ Sticker Die Cutting Machine photo-1
US$ 5,000 - 20,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Die-cutting Machine
Computerized:
Yes
Payment & Shipping
Payment Methods:
Port of Shipment:
NINGBO
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Type Die-cutting Machine
Computerized Yes
Place of Origin Zhejiang, China
Brand Name JIAYUAN
Model Number JMQ-320
Voltage 380V
Power(W) 5.5KW
Dimension(L*W*H) About 2800*1200*1700mm
Weight about 500kg
Certification CE
Warranty 1 year

Adhesive Label & Sticker Die Cutting Machine



Main Characteristics:

It is designed as high precision flat die cutting, pulling material, fixing position in printing’s both sides and lengthways are accurately tracking by three photocell eye, collecting waste, computer controlled cutting sheet or rewinding roll used for automatic labeling machine can be processed in one processing. It is very suitable for die cutting self-adhesive paper, label, dacron film trademark and laser anti-false trademark. It is a ideal and highly efficient supporting equipment for flexographic press, continuous screen printing machine, intaglio press and antifalse trademark die cutter. ( before machine power is on, do ground connection.)

Technical parameters:

Max. Web width

320mm

Max. Die cutting width

290mm

Max. Die cutting length

300mm

Die cutting speed

20-180 times/min

Positioning accuracy

±0.1mm

Max. unwinding diameter

500mm

Max. rewinding diameter

500mm

Power of main motor

2.2kw

Total power

3.5kw

Voltage

220v

Weight

1500kg

Dimension

2800×950×1400mm



PS: any doubts, call Ms Jessie, Tel: 086-577-65159218, Cel: 086-13587591360, Skype: monica913601
