JY-B300II Auto Cutter

JY-B300II Auto Cutter photo-1
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Application:
Textiles
Packaging Type:
Other, wooden box
Payment & Shipping
Payment Methods:
Port of Shipment:
FOB NINGBO
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Application Textiles
Packaging Type Other, wooden box
Packaging Material Paper
Automatic Grade Automatic
Driven Type Electric
Power 3.5kw
Place of Origin Zhejiang, China
Brand Name jiayuan
Model Number JY-B300II

Specifications

This machine is for cutting adhesive tape. Such as, TAC-TAPE, Kapton tape, double-side tape, masking tape, fabric tape, polyest





Model NO. : DMZ-B300I
Application:
Max.effective width: 1350mm /1600mm (optional)
Fits paper core : ø3 inch
Max. cutting diameter : Ø200mm
Min. cutting width : 1mm
Cutting Tolerancce : ±0.1
Max. Blade/knife Diameter: ø250mm
Voltage: 380V 50HZ (other voltage is optional)
Power : 4 KW

Knife feeding way : Air system

Details
USE:

This machine is for cutting adhesive tape.  Such as, TAC-TAPE, Kapton tape, double-side tape, masking tape, fabric tape, polyester tape, PE film, PVC insulated tape, PET tape, foam tape, 3M series, and so on.

CHARACTERISTIC:

1. Adopt PLC for controlling by automatic program.
2. Adopt air system for feeding blade.
3. The motors are drive by frequency converter which is vector output style. It characterizes in stable power output both
   in slow speed and high speed.
4. Adopt a digital panel for inputting data. The user can set the cutting size and some operation functions by it.
5. The user can set  only one groups of cutting size in one working cycle. Then the machine will cut automatically.
6. The user can operate the machine from the operation panel. It is very convenient for the user.
7. Adopt stepping motor system for fixing cutting position; precise ball screw drive. The cutter moves forward left or right
   on the linear motion guide which is very precise. The cutting is precise and stable.
8. The motors are stepless speed regulation; and theirs rotation direction is reversal. These functions are good for
   cutting different tapes.
9. Blade cooling system is adopted to the cutter. When cutting, it cools down and lubricates the knife automatically. The
   tape will never be melted.
10.The cutter angle is made manually. This way has a little complicated but it is useful when cutting tapes with different
   diameter; this is because different diameter requests different angle. It can also improve the cutting precision and
   make the operating simpler.
