ML24 PP FLEXIBLE STRAW AUTO MAKING MACHINE
DESCRIPTION
Model ML24 flexible straw auto making machine is a special machine of making flexible drinking straws. The straight straws supplied in the hopper at the top of machine ,passes through 18 sets of conveyor and 18 sets of needle and 1 sets of shaping wheel, delivered to output conveyor automatically.
Model |
ML24-4 |
ML24-5 |
ML24-6 |
||
Capability |
350~400pcs/min |
||||
Main motor |
1.5kW (VFD) |
||||
Automatic emergency stop equipment |
1set |
||||
Automatic counter |
1set |
||||
conveyor |
1set |
||||
Specifications of straw |
Inside Diameter |
Φ3.8mm |
Φ4.8mm |
Φ5.8mm |
|
Length of straight straw |
155~245mm |
190~260 mm |
190~260 mm |
||
Length of flexible straw |
140~235 mm |
175~245 mm |
175~245 mm |
||
Thickness of straw |
0.18±0.02 mm |
0.16±0.02 mm |
0.16±0.02 mm |
||
Top section length |
30~50 mm |
||||
Length of flexible part |
8~11 mm |
||||
Machine weight |
1000KG |
||||
Dimension |
1400mm(W)×2000mm (L) |
||||
Other specifications are customizable | |||||
TECHNICAL FEATURE
1. High efficiency and high production rate,
2. Automatic product counting,
3. Automatic stop in the event of straw jamming,
4. Hopper in stainless steel is set at conveyor,one man can operate two machines,
5. Special repairing safety button ,
1 If you have any question , please contact us for more information.
