Specifications
ML22 Double Corrugated straw making machine,it can make two corrugated parts ( flexible parts) on the straw.
ML22 Z-Shape Flexible Straw Auto Making Machine
DESCRIPTION
Model ML22 Z-shape flexible straw auto making machine is a special machine of making Z-shape flexible drinking straws. The straight straws supplied in the hopper at the top of machine ,passes through 12 sets of conveyor and 12 sets of double-screw needle and 1 sets of double-screw shaping wheel, delivered to output conveyor automatically.
TECHNICAL FE ATURE
1. High efficiency and high production rate,
2. Automatic product counting,
3. Automatic stop in the event of straw jamming,
4. Hopper in stainless steel is set at conveyor, one man can operate two machines,
5. Special repairing safety button ,
SPECIFICATIONS
Model |
ML22-4 |
ML22-5 |
ML22-6 |
||
Capability |
200250pcs/min |
||||
Main motor |
1.5kW (VFD) |
||||
Specifications of straw |
Diameter |
φ3.8mm |
φ4.8mm |
φ5.8mm |
|
Length of straight straw |
155245mm |
190245 mm |
190245 mm |
||
Length of flexible straw |
140235 mm |
175235 mm |
175235 mm |
||
Thickness of straw |
0.18±0.02 mm |
0.16±0.02 mm |
0.16±0.02 mm |
||
Top section length |
30 mm |
||||
Length of the first flexible part |
810 mm(10 teeth) |
||||
Length of the second flexible part |
56(6 teeth) |
||||
Machine weight |
1100KG |
||||
Dimension |
1200mm(W)×1800mm (L) |
||||
Other specifications are customizable | |||||
