JN3L-Csemi Automatic PET Bottle Blowing Machine
US$ 5100.00 - 5100.00
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Application:
Bottle
Plastic Processed:
PET
Payment & Shipping
Payment Methods:
Port of Shipment:
NINGBO
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Semi Automatic PET Bottle Blowing MachineUS$ 4,000 - 7,000MOQ: 1 Set -
JN6L-Csemi Automatic PET Bottle Blowing MachineUS$ 6,700 - 9,500MOQ: 1 Set
-
JN-2S2L Extrusion Blow Moulding MachineUS$ 27000.00 - 27000.00MOQ: 1 Set
-
JN-2S2L Extrusion Blow Molding MachineUS$ 27000.00 - 27000.00MOQ: 1 Set
-
Extrusion Blow MouldUS$ 500 - 2,000MOQ: 1 Set
Condition
New
Application
Bottle
Plastic Processed
PET
Blow Moulding Type
Stretch Blow Moulding
Automatic
Other, Semi Automatic
Place of Origin
Zhejiang, China
Brand Name
JUNENG
Model Number
JN3L-C
Voltage
design as you need
Dimension(L*W*H)
Blower:1400*600*1600mm;Heater:1750*600*1450mm
Weight
850kg
Certification
CE ISO
Warranty
1 Year
After-sales Service Provided
Engineers available to service machinery overseas
Product Description
one cavity, it can blow the bottles up to 4 liters;
two cavity, it can blow the bottles up to 2 liters
Product Feature
- Adopt the new type double bend arm and four pull rod-clamping structure(won the patent). Cross direction; middle mould board is move parallel;the distance between two mold board is adjusted by the chain wheel. Thus the clamping force is very strong.
- The machine frame is produced by the whole complete casting bottom, so that the machine is firm and running stable.
- Adopt the straight slide way, reduce the friction and lengthen the life of the machine.
- Double start working button, which is designed for avoiding for you injury.
- Power saving design that can increase your profits.
- The single direction of pre-form placing and bottle picking , which increase the output.
- Sepregate type air controlling system, which is designed for avoiding waste pollution.
- The stretching air cylinder is adjusted parallel from front to back, from left to right freely by regulator.
Products General Specifications
| Model No. | JN3L-C | JN3L-2C |
| Theoretical output | 700 1500 | 2000 1000 |
| Heating capacity | 9.8 | 15 |
| Max bottle volume | 4(one cav) 2(two cav) | 2(two cav) 4(one cav) |
| Blowing pressure | 3.5 | 3.5 |
| Motion pressure | 1.0 | 1.0 |
| Max diameter *height | 140*340 | 140*340 |
| Mould thickness | 120-220 | 120-220 |
| Weight | 850 | 1500 |
| Main machine | 1400*600*1600 | 1400*600*1600*2 |
| Heater | 1750*600*1450 | 2000*600*1450 |
