Lab Table Concentrator for Gold,silver,copper
Description de Produit
La table vibrante est une machine de sélection de mine pour la travail des bons minéraux par gravité. Elle est largement utilisée dans la sélection de Tin, tungstène, d'or, d'argent, de plomb, de zinc, de tantalum, de niobium, de fer, de magnésium, de ferrotitanium et de charbon.
La spécification technique
1, Modèle : MX1100X500 (mm)
2, longueur du choc 9---17(mm)
3, temps du choc 280~460 fois/minute
4, L'ajustement de la rangée de l'angle d'inclinaison de la surface pont : 0~10°
5, Capacité 20~60 kg/h
6, Consommation d'eau 0,3~10 L/minute
7, taille du pont
(Longueur *La largeur de l'extrémité de l'alimentation * la largeur de la décharge de minerai 1100X500X430 mm
8, Moteur Modèle : Y801-4 0,55 KW Vitesse de rotation : 1390 r/minutes
9,V belt : A----1245
10, Poids 230 KG
11, Dimensions des installations
(L*l*H) 1730*500*800 (mm)
MX-500 Shaking table is provided to the laboratory to
Carry out the mineral separation feasibility study, experiment and
For small ore dressing plant, is one of commonly used equipment for gravity dressing.
Suitable for separation of fine grain and small grain rare metal, ferrous metal,
Nonferrous metal, precious metal and coal. It can work independently,
Also can match with jig, screw separator, centrifugal separator and
Other processing equipment.
Running video in international exhibition
https://youtu.be/Yt4v9QHRBOU
Origin |
Jiangxi, China |
Trademark |
Mingxin |
Serial/Model NO. |
MX-500*1100 |
Standard |
Mining Machinery Table Vibration |
Type |
Gravity Separator |
Voltage |
380V |
Weight |
<1T |
Material |
Carbon Steel |
Material Feature |
Fire Resistant |
Certification |
BV,ISO9001:2008 |
Energy Saving |
Energy Saving |
Warranty |
1 Year |
Color |
Black |
Customized |
Customized |
Condition |
New |
Usage |
Lab Metal Separator |
Capacity |
20-100kg/H |
Gravity Working Method |
Eco Friendly Copper Separate Table |
Deck |
Fiber Glass,Wood Lacquer,Rubber,Epoxy Resin |
Efficiency |
99.9% |
Power |
0.55kw |
|
|
Note:
Please indicate which deck when you are ordering), can provide deck, motor of the shaking table, Slope modulator and other accessories independently
