Rectangle Compartment Side Way Action Type Jig has two types. One is left compartment side way jig, another is right compartment side way jig. The jig has fixed screen. It is available in separating metallic ores, such as tungsten and gold placer deposits as well as beneficiated tin ore, which not only can be separated fine materials, but coarse also. The largest feed size is 6-8mm but it can be 12mm in few cases.
Rectangle Compartment Side Way Action Type Jig is mainly composed of jig box, drive device, water distribution, diaphragm and bibcock. There are two jig buckets with different sizes and each diaphragm is divided into jig area and diaphragm area by clapboard. The rubber diaphragm pumping to make medium (water) moving is the jigging course. The triangle belt drives big belt pulley by electromotor so connecting rod of the eccentric gear and rocker are up and down moving. Another connecting rod is connected with the rubber diaphragm which is moving up and down to jig.
Based on the size of ore, we can change the stroke of connecting rod and choose different stroke to make the best jigging effect. The method of altering stroke per minute is to exchange a smaller belt pulley but there are two strokes per minute: 322r/m; 420r/m. The method of choosing stroke is to loose bolt and screw cap, take out bowel and move the relative place between eccentric adjusting sieve and eccentric shaft so there are 11 different strokes (0-25.3mm).
Model |
Jig chamber |
Jig Area (m2) |
Feeding Size (mm) |
Capacity (t/h) |
Stroke (mm) |
Stroke Per Minute (r/min) |
Hutch Water |
Water Pressure (kilo/cm2) |
Power |
Weight (kg) |
300×450 |
2 |
0.27 |
-12 |
3-6 |
0-26 |
322 |
2-4 |
1-1.5 |
1.1 |
745 |
Equipment:
Gravity Separation Machine, Flotation Machine, Crusher
Screening Equipment, Washing Machine, Lab Testing Machine, Shaking Table,
Jigger machine, Spiral Chute,Conveyor ...
More information here. /visiting/visitor-profile/
/
Do not hesitate to contact us now.
Tel:+86-797 810 8846
Fax:+86-797 810 8846
Meeting MINGXIN again with an own stand in the Hall.B3-No.6907
