Help CenterSTA 1200C to 1700C Mini High Temperature Electric Muffle Furnace
Related Products
-
STA-17MF-05 1700C High Temperature Laboratory Muffle FurnaceUS$ 1,000 - 8,000MOQ: 1 Set -
STA-MF1700-8L High Quality Muffle Furnace for LaboratoryUS$ 1,000 - 8,000MOQ: 1 Set
-
STA Energy Saving Heating Element Horizontal Tube FurnaceUS$ 750 - 3,500MOQ: 1 Set
-
High Temperature High Vacuum Sintering Tube Furnace SiC Carbon FurnaceUS$ 750 - 3,500MOQ: 1 Set
-
Compact Split Tube Furnace With Vacuum FlangesUS$ 750 - 3,500MOQ: 1 Set
High temperature muffle chamber furnace possesses the advantages of fast heating (20-40mins) , energy saving, high accuracy of controlling the temperature, reliable heat keeping , auto heating and cooling by programming and a furnace temperature nearing to the indoor. It is widely used in the laboratory and manufacture of the field of pottery, chemical industry, metallurgy, and glass industries, new material developing, machinery, fire-proof material, architecture, special material and etc.
Max. temperature inside furnace can be reached at 1700 degree.
Outstanding features
1. Uniform furnace temperature field
2. Low surface temperature
3. High acceleration to elevate the temperature
4. Energy saving
5. 50segment programmable program automatically controlling the temperature during the whole process
6. Provide Sigma data management software, which can record the history data and the temperature rising curve,
7. Multiple measures design for the safety protection. It is very safe and has a long life service.
8. Other service: provide ISO 9001:2008 certificate, Guarantee time at least 1 year, provide OEM/ODM service
the technical data of muffle furnace
Chamber size |
150x 150 x 150mm (WxHxD) |
Heating elements |
MoSi2 heater |
Elements layout |
2 sides |
Temperature controller |
30 segments programmable and PID numerical control |
Furnace structure |
Double shell with fan cooling |
Thermocouple |
B type |
Heating Rate |
0.1~15C/min (suggest </=10C) |
Maximum Temperature |
1600C |
Working temperature |
1500C |
Temperature accuracy |
+/- 0.5C |
Working Voltage |
Single-phase,AC,110/120/208/240V(choose any) |
Power frequency |
50H/60Hz(choose any) |
Rated Power |
3.5KW |
High temperature chamber furnace standard sizes:
Chamber size(STA-Mmm) |
Max. Temperature |
150x150x 150mm (6"x6"x6") |
1700.C |
150x150x 200mm (6"x6"x8") |
1700.C |
200x200x 200mm (8"x8"x8") |
1700.C |
200x200x 300mm (8"x8"x12") |
1700.C |
250x250x 300mm (10"x10"x12") |
1700.C |
300x300x 400mm (12"x12"x16") |
1700.C |
400x400x 400mm (16"x16"x16") |
1700.C |
500x500x 500mm (20"x20"x20") |
1700.C |
