STA-MF1700-8L high quality muffle furnace for laboratory
- Excellent uniformity inside the furnace chamber
- Double-walled housing with rear-ventilation to ensure extremely low outer-casing temperatures
- Parallel-guided door moving up-wards with hot insulation surface to the rear, away from operator
- Insulation made of high grade ceramic fibre with low thermal mass
- Door collar made of strong fire bricks to protect insulation against mechanical damages
- Wear-resistant fire brick insulation in the furnace bottom
- Delivery includes ceramic bottom plate
- Powerful SiC-rod heating elements mounted in two sides of the furnace providing very fast heating times
- Heating elements controlled by solid state relays for very precise temperature control, wear-free and noiseless
- Exhaust pipe in the furnace ceiling
Maximum temperature:1400C
Working temperature:1350C
Heating element:sic rod
Temperature control: SCR control, PID parameter self-setting function, 30 programmable periods
Heating Rate: 0~10.C / min (suggestion: < 10.C)
Temperature Accuracy: +/- 1.C
Working Voltage: AC 220V Single Phase 60/50 Hz (or according to your requirement)
Max. Power:8kw
the chamber size of the furnace
- 200×150×150 300×200×200 300×300×300 400×200×200
- 500×300×200 500×300×300 600×400×400 800×500×500
the air cooling system
Applications :
Muffle furnaces (High temperature resistance furnace) can be use on determination, metallographic
laboratory for analysis, research, or industrial and mining enterprises for high - temperature sintering
and metal work in the air for normalizing, annealing, hardening,for the Laboratory for universities,
scientific research and environmental protection unit.
Service:
1.We supply machines with battery technology support.
2 We can also supply a full set of materials for lithium battery including polymer battery, cylinder battery, mobile phone battery, EV battery.
3 We can also supply a full set of lithium battery equipment for lab research, pilot scale research and production line.
4 We can also supply a full set of battery technology for battery design, research and producing.
products showing:
