Remote Control Portable Digital Load Cell 200 Ton Wireless Loadcell
US$ 1 - 2
MOQ: 5 Pieces
Key Specifications
Get Latest Price
Model Number:
xh- loadcell
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
100 Ton Wireless Tension Sensor LED Wireless Loadcell for Load Test Water BagUS$ 1 - 2MOQ: 5 Pieces -
Deep-v Welded Steering Aluminum Fishing BoatUS$ 1 - 2MOQ: 1 Set
-
All-welded Aluminum Fishing Boat With Outboard EngineUS$ 1 - 2MOQ: 1 Set
-
Air Compressor for Breathing Air and Industrial GasesUS$ 1 - 2MOQ: 1 Piece
-
Portable Air Compressor With Honda EngineUS$ 1 - 2MOQ: 1 Piece
Model Number
xh- loadcell
Remote Control portable digital Load Cell 200 ton wireless loadcell
Application of Load Cell
Under Hook Crane weighing
Wire Rope and cable tension monitoring
Heavy lift and rigging
Aircraft manufacturing and repair
Structural load testing and certification
Crane and hoist calibration and proof load testing
Water weight testing and calibration
Shipping&receiving weighing
Manufacturing and heavy construction
Event staging and rigging
Offshore mooring anchor setting
Bollard pull testing and certification
Escalator comb impact testin
Features Of Load Cell
1. Rugged construction, fresh integrated sensor design
2. Accuracy: 0.05% of capacity
3. All fuctions and units are clearly display on the LCD (with backlighting),
4. LCD digital display 1 inch high for easy distant viewing.
5. Two user programmable Set-Point can be used for safety and warning applications or for limit weighing.
6. Long battery life on 3 standard "LR6(AA)"size alkaline batteries.
7. All commonly used internationally recognized units are available: Kg/t/lb/N/kN
8. Infrared Remote control easier to calibration(with password)
9. Infrared Remote control with many fuctions: "ZERO", "TARE", "CLEAR",
"PEAK", "ACCUMULATE", "HOLD", "Unit Change", "Voltage Check"and "Power OFF"
10. Local mechanical keys: "ON/OFF", "ZERO", "PEAK" and "Unit Change".
11. Low battery warnning.
12. RF wireless palm indicator
13. Wireless data receiver receives 100M
14. Opention: Shackle
Parameter Of Load Cell
1. Body Display 25mm (1") 5digits LCD with backlight
2. Indicator Display 25mm (1") 5digits LCD with backlight
3. Power on zero range 20% F. S.
4. Manual Zero Range 4% F. S.
5. Tare Range 20% F. S.
6. Stable Time ≤ 10 seconds
7. Overload Indication 100% F. S. + 9e
8. Max. Safety Load 125% F. S.
9. Ultimate Load 400% F. S.
10. Battery Life ≥ 50 hours
11. Battery Type: "LR6(AA)"size alkaline batteries. 1.5Vx3
12. Indicator Battery "LR6(AA)"size alkaline batteries. 1.5Vx4
13. Operating Temp. - 20° C ~ + 50° C
14. Operating Humidity ≤ 85% RH under 20° C
15. Remote controller distance: Min 15m
General parameter of Load Cell
| Model | Cap | Div. | A | B | C | D | φ | H | Material |
| (mm) | |||||||||
| HY-WL-01 | 1t | 0.5kg | 245 | 112 | 37 | 190 | 43 | 335 | Aluminum |
| HY-WL-02 | 2t | 1kg | 245 | 116 | 37 | 190 | 43 | 335 | Aluminum |
| HY-WL-03 | 3t | 1kg | 260 | 123 | 37 | 195 | 51 | 365 | Aluminum |
| HY-WL-05 | 5t | 2kg | 285 | 123 | 57 | 210 | 58 | 405 | Aluminum |
| HY-WL-10 | 10t | 5kg | 320 | 120 | 57 | 230 | 92 | 535 | Alloy Steel |
| HY-WL-20 | 20t | 10kg | 420 | 128 | 74 | 260 | 127 | 660 | Alloy Steel |
| HY-WL-30 | 30t | 10kg | 420 | 138 | 82 | 280 | 146 | 740 | Alloy Steel |
| HY-WL-50 | 50t | 20kg | 465 | 150 | 104 | 305 | 184 | 930 | Alloy Steel |
| HY-WL-100 | 100t | 50kg | 570 | 190 | 132 | 366 | 229 | 1230 | Alloy Steel |
| HY-WL-200 | 200t | 100kg | 725 | 265 | 183 | 440 | 280 | 1380 | Alloy Steel |
If you are interested in our Wireless Load Cell For Load Test, please feel free to contact us for more details
