Home > Products > Air Compressor > Portable 12v air compressor
Portable 12v air compressor
- 50 Unit / Units per Month
- Xiamen
- T/T Credit Card
You May Like
Product Details
Condition | New | Type | Screw | |
Configuration | Portable | Power Source | Diesel | |
Lubrication Style | Lubricated | Mute | Yes | |
Place of Origin | Fujian, China | Brand Name | DOOSAN | |
Model Number | VHP750 | Voltage | 24V | |
Dimension(L*W*H) | 4210mm*2000m*2220mm | Weight | 4000kg, 4000kg | |
Certification | EPA, EPA | Warranty | 1 year or 2000 hours | |
After-sales Service Provided | Overseas service center available |
Product Description
Specifications
12v air compressor1.Set up in 1996, Ingersoll Rand quality
2.Good cooling system
3.Top brand
4. oversea service
Portable 12v air compressor
Human design
-large capacity and high strength transparent oil box for oil level observation
-plastic wheel cover for clean
-foot pedal and handle are convenient for checking and repairing
-wide space for putting repairing tools
Rely on improved corrosion resistance with galvanneal sheet metal on the front panel and a three-step paint process over the entire enclosure. Ingersoll Rand portable air compressors deliver heavy-duty dependability and automatic safety features, plus a unique cool-box design that helps prolong component life.
Parameter:
Type | VHP750WCAT | MHP825WCAT | HP900WCAT | XP950WCAT | P1060WCAT | RHP750WCAT | SHP825WCAT |
Emission Standard | Tier3 | Tier3 | Tier3 | Tier3 | Tier3 | Tier3 | Tier3 |
Air Compressor | |||||||
Thread rod type | Single stage | Single stage | Single stage | Single stage | Single stage | Twin stage | Twin stage |
Air consumption (m³/min) | 21.2 | 23.3 | 25.5 | 27 | 30 | 21.2 | 23.3 |
Rated pressure(bar) | 13.8 | 12 | 10.3 | 8.6 | 7 | 20.7 | 17.2 |
Fuel capacity(L) | 550 | 550 | 550 | 550 | 550 | 550 | 550 |
Engine | |||||||
Manufactory | Caterpillar | Caterpillar | Caterpillar | Caterpillar | Caterpillar | Caterpillar | Caterpillar |
Model No | C9 | C9 | C9 | C9 | C9 | C9 | C9 |
Cylinder bore*Stroke | 112*149 | 112*149 | 112*149 | 112*149 | 112*149 | 112*149 | 112*149 |
Output Volume(L) | 8.8 | 8.8 | 8.8 | 8.8 | 8.8 | 8.8 | 8.8 |
Rated speed/idling | 1800/1350 | 1800/1350 | 1800/1350 | 1800/1350 | 1800/1350 | 1800/1350 | 1800/1350 |
Rated power(KW) | 224 | 224 | 224 | 224 | 224 | 224 | 224 |
Fuel/Cooling way | diesel/water | diesel/water | diesel/water | diesel/water | diesel/water | diesel/water | diesel/water |
Voltage(V) | 24 | 24 | 24 | 24 | 24 | 24 | 24 |
Unit | |||||||
length(mm) | 4210 | 4210 | 4210 | 4210 | 4210 | 4210 | 4210 |
Width(mm) | 2000 | 2000 | 2000 | 2000 | 2000 | 2000 | 2000 |
Height(mm) | 2220 | 2220 | 2220 | 2220 | 2220 | 2220 | 2220 |
Tread(mm) | 1660 | 1660 | 1660 | 1660 | 1660 | 1660 | 1660 |
Weight(kg) | 4000 | 4000 | 4000 | 4000 | 4000 | 4000 | 4000 |
Zhaoxing can help you to improve drilling efficiency and reduce the production cost.
1. Over 17 years practical drilling experience
2.Sold hundreds of drilling rig and air compressor
3. Continue to supply original spare parts and drilling tools
4. Provide professional drilling technical support
NO1.We can supply full range of drilling equipment to satisfy the requirements of the construction engineering and mine production.
Air compressor
Drilling rig
NO.2 We are not only having 17 years rich practical experience, but also have a batch of long-term cooperation top machinery manufactory resource.We provide original spare parts and drilling tools.
NO3.we have wide experience in mining, blast hole, anchor hole, geotherm hole. You can see our project case, and then you will believe our experience can help you.
When you want to purchase equipment, we can supply best configuration according to your project situation.
When you want to improve increase efficiency, we can supply reform project for you.
When you want to decrease drilling tool cost, we can supply good quality and low price product to you.
When your equipment need to repair, we can supply technical service.
In a word, if you cooperation with me, you will get benefit as soon as possible.
Our Certificate
Not only are we one of the premier suppliers of DTH equipment, we have also become specialists in solution based large diameter rock drilling packages, providing not only large diameter hammers and bits, but also shrouded drill pipes, helicoidal pipes and casing advancing systems. Working with you from tender stage to contract completion helps you get your projects completed on time and on budget.
