2015 newest openwrt wireless lan card module
ThisModuleuseAR1021XasSoc. The AR1021X is a highly integrated, system-on-
a-chip solution for 2.4/5 GHz IEEE 802.11n 2x2 MIMO WLAN, providing improved link robustness, extended range, and increased throughput and performance.
The AR1021X supports two-stream 802.11n and includes the Qualcomm Atheros internal
Efficient Power Amplifier (EPA) technology. It integrates dual-band power amplifiers and receive low-noise amplifiers, and 2.4GHz Tx/Rx switches. Advanced architecture and protocol techniques save power during sleep, stand-by and active states.
The AR1021X supports USB, SDIO, and SPI host interfaces, and multiple peripheral interfaces including UART, SPI, xMII, I2C and GPIO. All internal clocks generate from a single external crystal. The AR1021X supports reference clocks ranging from 19.2to 52MHz.
1.Characteristics:
n All-CMOS IEEE 802.11a/b/g/n 2x2 single-chip
n USB2.0 at 480 Mpbs, with LPM support, using an in tegrated controller and PHY
n SDIO 2.0 interface with 200 Mbps throughput
n MII/RMII/RGMII interface
n Extensive hardware support for WLAN coexistence throughLPC message passing
n Power and clock management for extended battery life
n Green-Tx power saving
n Low-power listen mode and radio retention for reduced receivepower consumption and sleep current
n Support for STBC and transmit beamforming (TxBF)
n Support for LDPC encoded transmission and reception
n Maximum Likelihood (ML) decoder for multistream 802.11n reception
n Internal OTP memory for calibration data
n Integrated RF switch for 2.4 GHz Figure 1-1 Product photos
n 2.4 G of RX and TX configuration LNA and PA respectively
n Data rates of up to 54 Mbps for 802.11a/g and 144.4 for 802.11n HT20, 300Mbps for HT40
n Advanced power management to minimize standby, sleep and active power
n Security support for WEP, WPA, WPA2, WAPI, as well as WPS and protected managements frames
n Full 802.11e QoS support including WMM and U-APSD
n 802.11e-compatible bursting
n Support for the IEEE 802.11e, h, i, and j
n WEP, TKIP, and AES hardware encryption
n Reduced (short) guard interval
n Frame aggregation with A-MPDU
n MIMO power save
n Block ACK
n UART for console support
n 2/3/4-wire Bluetooth coexistence support
n JTAG-based processor debugging supported
n Product size: Product size: 26.0mm * 72.7mm(±0.1mm)
n Product photos (Figure 1-1)
