LT150-6

Name: LT150-6
Brand: LuTong
SKU: 111184653
Availability: InStock

Luoyang Lutong Heavy Industry Machinery Co., Ltd.

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Henan, China

Brand Name:

LuTong

Model Number:

LT150-6

Payment & Shipping

Payment Methods:

Port of Shipment:

China

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Henan, China

Brand Name LuTong

Model Number LT150-6

Condition New

Moving Type Crawler Excavator

Operating Weight 15000kg

Bucket capacity 0.52m³

Maximum Digging Height 8500mm

Maximum Digging Depth 5560mm

Machine Weight 15000kg

Max Digging Radius 8245mm

Specifications

1.CE certification
2. Imported yanmar 4TNV106T enginee;
3.Two-speed independent piston motor

Enginee:
Model	Imported yanmar 4TNV106T enginee
Type	Water-cooled .direct-spary.4 storke

BoreXstorke	106mmX 125 mm
Displacement	4.412 L
Rated power	69.9KW/2200.rpm(ISO9249)
Max.output torque	388.3N.m/1600.rmp(ISO9249)
Hydraulic System:
Main pump	2XColumn pump+ Column pump
Max.displacement	132.6 ml/r
ure
Boom,Arm,Bucket	35Mpa
Travel circuit	35Mpa
Swing circuit	24Mpa
Control circuit	4Mpa
Pilot pump	4Mpa
Main valve	9 Variable
Swing Syetem:
Parking brake	When swing control rod in the neutral automatic hydraulic lock


Tail swing radius	2130 mm
Swing ball bearing	Heavy load.sealed oil lubrication

Fuel tank	220L
Hydraulic oil tank	80L
Cool ant	20L
Travel drive	2X3.5L
Sing drivew	3.8L
Air conditioner	1kg
Operating weight	15000kg
Cylinger:
Bore X Stroke X diameter
Boom	2XΦ105X990X75(mm)
Arm	Φ115X1060X80(mm)
Bucket	Φ100X6852X75(mm)
Blade
