LUTONG1104 110hp 4WD Wheel-style Farm Tractor

LUTONG1104 110hp 4WD Wheel-style Farm Tractor photo-1
US$ 14,000 - 23,000 MOQ: 1 Unit
Key Specifications
Get Latest Price
Condition:
New
Type:
Wheel Tractor
By wheel:
4WD
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai/Qingdao
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Type Wheel Tractor
By wheel 4WD
Usage Farm Tractor
Drive Type Gear Drive
Power(W) 81 kw
Certificate CE
Brand Name LUTONG
Model Number LT1104
Place of Origin Henan, China
After-sales Service Provided Engineers available to service machinery overseas

Specifications

LUTONG1104 110hp 4WD wheel-style tractor
fessional factory
2.ISO9001:2000

Main Features

    1.Adopting Dong fang hong famous diesel engine,good reliability,large torque reserve,low fuel consumption, high economic benefits;

    2.Adopting 13 inch double clutch ,high transfer ability,reliable effect,operation more comfortable;

    3.Gear box use 4X(3+1),12 forward gears,4 reverse gears, gear are reasonable,high working efficiency;

4.Adopt independent power output device,steady transmission,large bearing capacity;

    5.Using independent oil hydraulic steering system operation,flexible operation,reliable energy saving;

    6.Using disc brakes,large braking torque,good braking effecting;

    7.Using forced type lifter, reliable use, convenient maintenance;

    8.Final drive adopts planetary reduction structure,compact structure, large reduction ratio;

    9.New streamlined appearance, greaceful ,HY,fashion;



Model

LT1104

type

4X4

Overall dimension

Length

4650



Width

4650



High

2970

Wheelbase(mm)

2449

Front wheel tread(mm)

1610

Rear wheel tread(mm)

1620-2020

Min.ground clearance(mm)

/

Min.turning radius(mm)

One side brake(m)

4.8±0.2



One side not brake(m)

5.5±0.2

Min.using mass(kg)

4249

Gear box

F16/R8

Speed(km/h)

going(km/h)

1.58-33.69



retread(km/h)

2.41-34.67

Engine

model

LR6B3-23



Rated power

(kw)

81



Rated speed

(r/min)

2300

Tyre type

Front tyre

14.9-24



Rear tyre



Steering system type



Max.lift-off weight(KN)

19.5

PTO type



PTO speed(r/min)

760/1000(540/1000 or 540/760 or 760/850 is also available)

PTO power(kw)

68.9

Roots in control mode

Height adjustment,floating control

Max.traction(KN)

25.7

Counterweight quality(kg)

front

270



rear

470
