LUTONG1104 110hp 4WD wheel-style farm tractor
- 100 Unit / Units per Month
- Shanghai/Qingdao
- T/T
Product Details
Condition: | New | Type: | Wheel Tractor | By wheel: | 4WD |
Usage: | Farm Tractor | Drive Type: | Gear Drive | Power(W): | 81 kw |
Certificate: | CE | Brand Name: | LUTONG | Model Number: | LT1104 |
Place of Origin: | Henan, China | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Specifications
LUTONG1104 110hp 4WD wheel-style tractorfessional factory
2.ISO9001:2000
Main Features
1.Adopting Dong fang hong famous diesel engine,good reliability,large torque reserve,low fuel consumption, high economic benefits;
2.Adopting 13 inch double clutch ,high transfer ability,reliable effect,operation more comfortable;
3.Gear box use 4X(3+1),12 forward gears,4 reverse gears, gear are reasonable,high working efficiency;
4.Adopt independent power output device,steady transmission,large bearing capacity;
5.Using independent oil hydraulic steering system operation,flexible operation,reliable energy saving;
6.Using disc brakes,large braking torque,good braking effecting;
7.Using forced type lifter, reliable use, convenient maintenance;
8.Final drive adopts planetary reduction structure,compact structure, large reduction ratio;
9.New streamlined appearance, greaceful ,HY,fashion;
Model | LT1104 | ||||
type | 4X4 | ||||
Overall dimension | Length | 4650 | |||
Width | 4650 | ||||
High | 2970 | ||||
Wheelbase(mm) | 2449 | ||||
Front wheel tread(mm) | 1610 | ||||
Rear wheel tread(mm) | 1620-2020 | ||||
Min.ground clearance(mm) | / | ||||
Min.turning radius(mm) | One side brake(m) | 4.8±0.2 | |||
One side not brake(m) | 5.5±0.2 | ||||
Min.using mass(kg) | 4249 | ||||
Gear box | F16/R8 | ||||
Speed(km/h) | going(km/h) | 1.58-33.69 | |||
retread(km/h) | 2.41-34.67 | ||||
Engine | model | LR6B3-23 | |||
Rated power (kw) | 81 | ||||
Rated speed (r/min) | 2300 | ||||
Tyre type | Front tyre | 14.9-24 | |||
Rear tyre | |||||
Steering system type | |||||
Max.lift-off weight(KN) | 19.5 | ||||
PTO type | |||||
PTO speed(r/min) | 760/1000(540/1000 or 540/760 or 760/850 is also available) | ||||
PTO power(kw) | 68.9 | ||||
Roots in control mode | Height adjustment,floating control | ||||
Max.traction(KN) | 25.7 | ||||
Counterweight quality(kg) | front | 270 | |||
rear | 470 |
