Sawdust Drying Machine
Brief description of sawdust drying machine:
Sawdust drying machine is a low fuel consumption and high efficiency working dryer machine, it can dry the material with 85% to the final moisture content below 13%, it can used to dry sand, coal, chicken manure, palm fiber etc.
Technical specification of sawdust drying machine:
This is only a reference for you, if you have fixed data, we can design machine according to your required.
Application of sawdust drying machine:
The sawdust drying machine can be used in building materials, metallurgy, chemical industry, cement plant for drying of limestone,coal powder,slag, clay stone food vegetables,cassava and other.
This sawdust drying machine is formed by rotary body, lifting blade, driving device, supporting device and sealing.
sawdust drying machine is a low-fuel-consumption and high efficiency of drying equipment. It can be used to dry the material with a moisture content below 85% to a final moisture content below 13%,. It is applicable in animal farming, food brewing, sugar and pharmaceutical industries dealing with high humidity waste, as well as a variety of chemical raw materials.
Structure of sawdust drying machine:
Sawdust drying machine mainly consist of: 1) Furnace + 2) Connection pipes between
dryer and furnace + 3) Feeder machine + 4)Temperature detector + 5) roller ring
+ 6) Big gear(45# steel) + 7) Transmission parts ( Motor, Reducer, Bearing,Small gear)
+ 8) Carrier Roller + 9) Discharge machine + 10) Cyclone + 11) Water dust collector +
12) Air induced fan
In addition, we can also according to customer's specific requirements and actual situation to design coal gasifier, combustor, belt conveyor, dosing machine and so an.
Working priciple of sawdust drying machine:
Sawdust drying machine is mainly for drying the small size raw material less than 30mm, The moisture content less than 85%.
Firstly, The sawdust drying machine enter into the drying system by conveyor or bucket conveyor, the raw material raised by lifting plate to making the raw material and heattotally contact with each other.
The raw material are evenly distributed in sawdust cylinder,at the start of dryer and the end of the dryer have temperature detector, so you can check everywhere temperature inside the sawdust drying machine.
After the sawdust drying machine have fan, it will absorb the hot air into the dryer and finally make the material to dry.
Between the industrial dryer and fan have cyclone, it can collect the dust out from the sawdust drying machine.
The main features about sawdust drying machine:
1. The sawdust drying machine have high degree of mechanization, large production capacity and continuous working.
2.With simple and excellent structure, the material running smoothly inside the industrial dryers cylinder.
3.The sawdust drying machine with less mechanical failure, low maintenance and low power consumption.
4.The dryers work uniformly and the drying product is very good.
5.With complete dust removal equipment and protect the environmental.
6.Sawdust drying machine with no dust spilling.
7.Easy to operate and have a good operating environment.
1.Guoxin Machinery Factory has been specialized in dryer machine for more than 20 years with a lot of experience exported to US,UK,Africa,Vietnam,Nigeria,Malaysia etc up to 60 countries.
2.We are a manufacture factory,so the price we offer you is the bottom price.
3.Quick and safe delivery:don't worry about the delivery,we have a professional team to delivery the machines for DHL,air transportation,sea transportation.
4.Full varieties of models for choice.
5.Best price,best service,attracting design,high quality.
6.Everyone including the boss ,workers,trading members in our company is very friendly.We will be very happy if you can come to China to visit our factory and plant.
1) How is the quality of your products?
Our products are manufactured strictly according to national and international standard, and we take a test on every machine before delivery.
2) What guarantee do you provide?
If the quality is not consistent with the description as we said or promised before you place order, we promise you 100% refund.
3) How about price?
We have our own factory and can give you the lowest price, besides, we have a policy that " for saving time and absolutely honest business attitude, we quote as low as possible, discount can be given according to quantity"
We are professional manufacturer rotary drum dryer, mesh belt dryer and microwave dryer. If you are interested in our production you can contact me any time.Because we have factory byt ourself, so welcome to visit our factory if you have free time.We will offer best suitable machine for you with best price.
looking forward your inquiry!
Photos of Guoxin:
Guoxin has CE certificate approved:
