PROCESS
This air classifiers series IMC, has been developed especially for ultra fine cut points.
With the IMC series we extended our program of the ITC—series.
The main point of its development was to achieve a high fineness of the end product.
A good sharpness, high efficiency and low specific energy consumption with highest fines output were the guideline for this target.
We could achieve these criteria by optimizing the dynamic of air flow, the material resistance and the multi-wheel concept.
With this series we can offer an air classifier to meet even the most exciting product requirements.
The classifying wheel of the series IMC is especially developed for highest strength during production.
The wheel is placed in a horizontal position. The rotor and the drive are designed as a complete module.
Also a wear protected wheel can be supplied.
FEATURES
- 1-6 rotors in a classifier chamber
- Direct driven rotors
- High speed drive system
- Adjustable of cut point by variable rotor speed via frequency converter
- Fine classification with high performance by special wheel design
- Feed from bottom with main air stream for high feed rates
- Best sharpness by most effective coarse classifying zone
- Construction material can be mild steel, stainless steel or wear protected
- The solid construction and the selected materials of construction give a long life time with low maintenance costs.
High Efficiency and Capacity Fine Powder air Classifier IMC with after-sales engineering sevice
Chemicals, minerals (such as calcium carbonate, kaolin, classification of quartz, barite, talc, graphite and other non-metallic mineral products), ceramic, refractory material, medicine, pesticide, food, new materials and other industries.
Air Classifier IMC Series with Single Rotor
|
Type Parameters |
IMC60 |
IMC100 |
IMC140 |
IMC200 |
IMC260 |
IMC315 |
IMC400 |
IMC500 |
IMC570 |
Product Fineness (D97um) |
3~75 |
3~75 |
3~75 |
3~75 |
3~75 |
3~75 |
4~75 |
5~75 |
5~75 |
Throughput (T/h) |
0.005~0.02 |
0.01~0.1 |
0.05~0.3 |
0.1~0.6 |
0.2~1.0 |
0.5~3 |
0.8~4 |
1.5~6 |
2~8 |
Power (KW) |
3 |
6 |
4 |
5.5 |
7.5 |
15 |
18.5 |
22 |
30 |
Airflow (m³/h) |
300 |
600 |
1000 |
1500 |
2000 |
3000 |
4600 |
7500 |
9000 |
Remarks: Capacities based on limestone (density 2,7 kg/dm3)
Feed capacity approx.3-times fines capacity
Fines content in fee approx.70%
Data depending on tests
Quality guarantee is for one year. During one year, if there is any problem or destroy (non-artificial damage), we will repair or change for free. After one year, if there is any problem, we will still supply good service, and we will charge cost if parts needed to be changed.
- Flow sheet of the process
- Electrical interlocking sequence
- Dimension drawings for supplied equipment
- Operation manuals
- Technical information and specification for local supply
- Engineering drawings for local supplies
- Technology data and drawings for installation and commissioning
- Spare parts list
Q &A:
1. Why choose QINGDAO SHINA as supplier?
A: QINGDAO SHINA has a perfect team with more than 20 years experience. Technology of QINGDAO SHINA is original from Germany. What customers get from QINGDAO SHINA is not only one set of machine, but together with know-how.
2. What should I do if I want to start a new project or extent production, but I have no idea what should I do at the beginning?
A. Please send email to QINGDAO SHINA and tell QINGDAO SHINA your situation of the project, QINGDAO SHINA will supply one feasibility study report together with detailed proposal and technical suggestions only for your project.
3. How about the quality of machine manufactured by QINGDAO SHINA?
A. QINGDAO SHINA business concept is: “Start a career with essence, win through high quality”. QINGDAO SHINA follows the principle of “quality is most important” when manufacturing each machine. Besides, QINDAO SHINA decides to lengthen quality guarantee of each machine or production line to 1.5 years so that customers can use machine without worry.
4. How about the after-sales service of QINGDAO SHINA?
A. QINGDA SHINA has a good after-sales service team, all the engineers in the team has more than 10 years experience. QINGDAO SHINA can promise that after the machine arriving at customer’s factory, we will arrange our engineer in time accordingly to make installation. Commissioning and test run. QINGDAO SHINA’s customer service concept is: customers are always the first!
5. How can I start the machine when getting machine?
A. QINGDAO SHINA will arrange engineers with rich experiences to customer’s factory for installation, commissioning and test run. After then, engineers will make training for workers about how to start machine or production line until workers can start machine very good alone.
6. If there are some problems or questions during running machine or production line, what should I do?
A. Please call QINGDAO SHINA in time if you have any questions during production. QINGDAO SHINA will reply customers in time to make sure the production won’t be delayed.
