Factory Supply Belt Dryer Cassava Chip Drying Machine
Description of Cassava Chip Drying Machine:
Our Cassava Chip Drying Machine belong to Belt Dryer, is a batch, continuous production drying equipment, use Steel Mesh for carrying materials for continuous drying, suitable for line, best suitable appropriate Assembly Line. As the conveyor belt is mesh, so it is most appropriate for drying block, granular, strip, sheet materials (such as: Coal Briquettes, Food, Flour, Vegetables).
It can be used to bake and dry the Food, Flour and Vegetables. The Cassava Chip Drying Machine can bake all kinds of the inflating food, pet food, TVP/TSP food, peanut, nut, chew nut and so on.
Features of Cassava Chip Drying Machine:
1.Single Layer Belt Dryer and Multi-layer Belt Dryer both can be manufactured, layers of Cassava Drying Machine depends on capacity you need.
2.The Belt Dryer Cassava Chip Drying Machine can be used separately,also used to support other other equipments in a line.
3.Heating methods of Cassava Chip Drying Machine:Electric heating; Steam heating; Hot air heating.
Outstanding Advantages of Cassava Chip Drying Machine:
1. The Cassava Chip Drying Machine has the compact structure, small occupying, large drying area, small surface area, slight radiating heat and high thermal efficiency.
2.Belt adopts the stainless steel,it is very suitable for food industry.
3. Running speed of belt in Electric Heating Cassava Chip Drying Machine can be controlled (frequency)
4. Temperature of Cassava Chip Drying Machine can be controlled willfully and designed according to the need.
5. Stainless steel insulation board,there are insulation cotton in the middle
6. Flexible detachable metal drawers to catch some scrap in the bottom of Cassava Chip Drying Machine.
Hot air heating Cassava Chip Drying Machine as below:
Working principle of Cassava Chip Drying Machine:
The materials cassava evenly tile in the mesh belt, mesh belt using 12-60 mesh steel belt, the materials move back and forth in the Cassava Drying Machine dragged by transmission device. The hot air produced by Electric heating tube(Burner, Heating stove etc. ) go through Cassava Chip Drying Machine, make the moisture of wet material evaporate, and discharge from the wet hole, so as to achieve the purpose of drying.
Hot air heating Cassava Chip Drying Machine Flowchart
Technical Data of Cassava Chip Drying Machine:
The structure of Cassava Chip Drying Machine:
1.Feed port, 2.Distributor, 3.Main body, 4.Cotton Insulation, 5.Mesh belt,
6.Reducer, 7.Chain Wheel, 8.Roller, 9.Discharge port 10.Dregs drawers,
11.Frequency modulation motor, 12.Transmission bracket,
13.Heating source(Heating tubes, burners etc.) 14.Induced draft fan
Transportation of Cassava Chip Drying Machine:
Some Clients from World to buy our Chip Drying Machines:
We also have Cassava Peeling and Slicing Machine, also Cassava Flour Mill, Cassava Flour Packing Machine for your reference.
Any questions about Cassava Chip Drying Machine, please contact me, send inquiry to me!
