Factory Supply Stainless Steel Vegetable Mesh Belt Dryer
Description of Vegetable Mesh Belt Dryer :
Our Vegetable Belt Dryer is a batch, continuous production drying equipment, use Steel Mesh for carrying materials for continuous drying, suitable for line, best suitable appropriate Assembly Line. As the conveyor belt is mesh, so it is most appropriate for drying block, granular, strip, sheet materials (such as: Coal Briquettes, Food, Flour, Vegetables).
It can be used to bake and dry the Food, Flour and Vegetables. The Vegetable Mesh Belt Dryer can bake all kinds of the inflating food, pet food, TVP/TSP food, peanut, nut, chew nut and so on.
Features of Vegetable Mesh Belt Dryer :
1.Single Layer Belt Dryer and Multi-layer Belt Dryer both can be manufactured, layers of Vegetable Mesh Belt Dryer depends on capacity you need.
2.The Vegetable Mesh Belt Dryer can be used separately,also used to support other other equipments in a line.
3.Heating methods of Vegetable Mesh Belt Dryer :Electric heating; Steam heating; Hot air heating.
Outstanding Advantages of Vegetable Mesh Belt Dryer :
1. The Vegetable Mesh Belt Dryer has the compact structure, small occupying, large drying area, small surface area, slight radiating heat and high thermal efficiency.
2.Belt adopts the stainless steel,it is very suitable for food industry.
3. Running speed of belt in Electric Heating Vegetable Mesh Belt Dryer can be controlled (frequency)
4. Temperature of Vegetable Mesh Belt Dryer can be controlled willfully and designed according to the need.
5. Stainless steel insulation board,there are insulation cotton in the middle
6. Flexible detachable metal drawers to catch some scrap in the bottom of Vegetable Mesh Belt Dryer .
Hot air heating Vegetable Mesh Belt Dryer as below:
Working principle of Vegetable Mesh Belt Dryer :
The materials cassava evenly tile in the mesh belt, mesh belt using 12-60 mesh steel belt, the materials move back and forth in the Cassava Drying Machine dragged by transmission device. The hot air produced by Electric heating tube(Burner, Heating stove etc. ) go through Vetetable Mesh Belt Dryer , make the moisture of wet material evaporate, and discharge from the wet hole, so as to achieve the purpose of drying.
Hot air heating Vegetable Mesh Belt Dryer Flowchart
Technical Data of Vegetable Mesh Belt Dryer :
The structure of Vegetable Mesh Belt Dryer :
1.Feed port, 2.Distributor, 3.Main body, 4.Cotton Insulation, 5.Mesh belt,
6.Reducer, 7.Chain Wheel, 8.Roller, 9.Discharge port 10.Dregs drawers,
11.Frequency modulation motor, 12.Transmission bracket, 13.heating source
14.Induced draft fan
Transportation of Vegetable Mesh Belt Dryer :
Some Clients from World to buy our Vegetable Mesh Belt Dryer :
Any questions about Vegetable Mesh Belt Dryer, please contact me, send inquiry to me!
